EcoCore AP Mini Series New Zealand's Smallest* High Wall Indoor Unit Ideal for above doorways or where space is limited. *Indoor unit total volume size of 0.034m3 Have you met the Mighty Mini yet?
EcoCore AP Mini The EcoCore AP Mini High Wall Heat Pump brings leading-edge technology and features in New Zealand's smallest† high wall indoor unit. The perfect solution for bedrooms or small rooms where space is at a premium. Pint-sized but big on performance, the AP Mini is packed with features that maximise energy efficiency. New Zealand's Smallest† High Wall Indoor Unit Specifically designed where space is at a premium, the 250mm high by 760mm wide footprint makes it ideal for positioning above doorways in bedrooms and home offices. Now smaller spaces no longer need to miss out on year-round comfort. Small Enough to Fit Above Doorways With a 16.4%* size reduction in height and 5% reduction in width when compared to the bigger EcoCore AP 25-50 models, they can even be installed in very tight places that would traditionally not have been possible such as above doorways. Energy Efficient EcoCore Inverter Technology Superior energy efficiency is achieved by incorporating a large, high density heat exchanger, an advanced high efficiency fan motor and a next-generation inverter compressor that uses more efficient R32 refrigerant. More Environmentally Friendly R32 Refrigerant With a global warming potential that is 30% lower compared to older refrigerants such as R410A, next-generation R32 refrigerant has a much lower environmental impact. Furthermore, zero ozone depleting R32 is easier to reuse and recycle. AP MINI SIZE COMPARISON AP25/35/42/50 AP20 Mini *Indoor unit height compared to the MSZ-AP25/35/42/50 range. †Indoor unit total volume size of 0.034m3 Meet the Mighty Mini
Dimensions (WxDxH): 760 x 178 x 250mm MSZ-AP20VGD Heating Capacity: 2.5 kW | Cooling Capacity: 2.0 kW Dual Barrier Coating Maximises Efficient Performance The patented and world’s first Dual Barrier Coating from Mitsubishi Electric prevents dust and dirt from accumulating on the inner surface of the indoor unit. By keeping your heat pump clean year-round you can rest assured your heat pump will always perform at its best. Washable Air Purifying Filter The EcoCore AP Mini is equipped with an Air Purifying Filter. This washable filter traps particles such as dust, pollen and other airborne contaminants, generating stable antibacterial and deodorising effects. The size of the three-dimensional surface has been increased from previous models, enlarging the filter capture area. These features give the Air Purifying Filter better dust collection performance than conventional filters. Horizontal Airflow The EcoCore AP Mini eliminates uncomfortable draughts with Horizontal Airflow in Cooling Mode, by spreading airflow evenly across the ceiling. Blue Fin Coating – Built to Withstand the Elements The heat exchanger of the outdoor unit has been treated with Blue Fin AntiCorrosion Treatment, slowing the corrosion process caused by salt and sulphur in the air especially in coastal and high sulphur areas. 7-Day Programmable Controller All EcoCore Heat Pumps come standard with a 7-Day Controller, so you can customise your heating and cooling needs to your lifestyle with as much energy efficiency as possible. Optional Wi-Fi Control! Never Return to a Cold Home Again With optional Wi-Fi Control* you can pre-heat or cool a room no matter where you are. On the way home, running late, coming home early, or even when you're in a different country, with Wi-Fi Control you'll always arrive home to total comfort. Wi-Fi Control is Amazon Alexa and Google Home enabled so you can take your comfort to the next level and enjoy hands-free heat pump control. Optional Plasma Quad Connect for Cleaner, Healthier Air Designed to integrate with your existing AP Mini Heat Pump, this highperformance two-stage advanced air filtration module, cleans and minimises dust and other allergens for better indoor air quality, all year round. * Wi-Fi adapter must be mounted externally. Comparison of dirt on heat exchanger, fan and air duct. (Factory simulated in-house comparison.) No Dual Barrier Coating (after 10 years) With Dual Barrier Coating Heat Exchanger Fan Air Duct Close-up of Air Purifying Filter Advanced Air Filtration Optional
EcoCore AP Mini Series Specifications For more information please visit our website or call our Customer Service Team. www.mitsubishi-electric.co.nz | 0800 784 382 PRINTED Mar 2022 EER = Energy Efficiency Ratio COP = Coefficient of Performance AEER = Annual Energy Efficiency Ratio ACOP = Annual Coefficient of Performance SPL = Sound Pressure Level ¹ SHi = Super High ² Low–SHi = Low–Medium–High–Super High ³ SPL measured under rated operating frequency * Indoor Sound Levels rated at lowest fan speed ‡ Star Ratings based on the Seasonal Energy Efficiency Rating standard for New Zealand - cold zone [GEMS 2019] † Maximum length is inclusive of height differential i.e. (20/12) means the pipe can be 12m high and 8m across for a total length of 20m. Rating Conditions (AS / NZS 3823). Cooling: Indoor: 27°C DB, 19°C WB. Outdoor: 35°C DB Heating: Indoor: 20°C DB Outdoor: 7°C DB, 6°C WB. QUICK GLANCE TYPE High Wall System SERIES EcoCore AP Mini Series MODEL MSZ-AP20 REFRIGERANT R32 INDOOR UNIT MSZ-AP20VGD OUTDOOR UNIT MUZ-AP20VG COOL 2.0kW 4.35 EER 21 dBA* HEAT 2.5kW 4.17 COP 21 dBA* ENERGY RATING ‡ 3.5 2.0 COOL Capacity Rated [kW] 2.0 Min-Max [kW] 0.6 - 2.7 Input Rated [kW] 0.46 EER 4.35 AEER 4.31 Star Rating 3.5 Indoor Sound Level (Quiet) [dBA] 21 (Low-SHi*) [dBA] 26-30-35-42 Running Current (In+Out) [A] 2.6 Air Volume In (SHi*) [L/s] 115 HEAT Capacity Rated [kW] 2.5 Min-Max [kW] 0.5 - 3.5 Input Rated [kW] 0.6 COP 4.17 ACOP 4.14 Star Rating 2.0 Indoor Sound Level (Quiet) [dBA] 21 (Low-SHi*) [dBA] 26-30-35-42 Running Current (In+Out) [A] 3.2 Air Volume In (SHi*) [L/s] 122 Controller Standard 7-Day Programmable Controller Optional Wired 7-Day Timer Optional: PAR Controller (Interface Required) Wi-Fi Optional: MAC-568IF-E Power Supply (Powered From Outdoor Unit) 230 V / Single Phase / 50 Hz Maximum Current [A] 6.9 Indoor Dimensions (WxDxH) [mm] 760 x 178 x 250 Weight [kg] 8.2 Outdoor Dimensions (WxDxH) [mm] 800 x 285 x 550 Weight [kg] 31 Sound Level - SPL (Cooling/Heating) [dBA] 47 / 48 Piping Diameter (Liquid/Gas) [mm] 6.35 / 9.52 Max. Length/Height† [m] 20 / 12 Chargeless Piping Length [m] 7 Operation Range Outdoor Cooling [˚C] -10 / 46 Heating [˚C] -15 / 24 Indoor Unit Colour White
