LN Black Diamond Smart Series Personalised Comfort Redefined New Zealand’s Most Trusted Heat Pump Our most intelligent, energy-saving heat pump yet.
LN Black Diamond Smart Series Reflect Your Design Personality Featuring a striking flat panel design, the Black Diamond Smart Series is available in three unique reflective colour finishes – White Diamond, Red Diamond and Black Diamond, that change depending on the light in the room. Now you can make a real interior design style statement with your heat pump colour choice. Optional HyperCore The Black Diamond Smart Series 2.5–5kW capacities are available with optional HyperCore Technology. While ordinary heat pumps produce less heat below 7°C, Mitsubishi Electric HyperCore Technology guarantees to continue to deliver its full rated heating capacity right down to -15°C, so you stay warm when you need it most. The LN Black Diamond Smart Series sets the new standard in personalised comfort and style. Available in three reflective colours, the range is packed with advanced features including Plasma Quad Plus Filtration ideal for allergy sufferers, the 3D i-See Sensor for customised heating or cooling and Builtin Wi-Fi Control Energy Monitoring! Ambient Temperature °C MSZ-LN50 HyperCore® 6kW Heating High Wall Heat Pump Ambient Temperature vs Heat Delivery Kilowatt Heat Output STANDARD Inverter 6kW Heating High Wall Heat Pump * The Black Diamond Series LN60 is not available with HyperCore Technology.
3D i-See Sensor The 3D i-See Sensor detects the presence and position of people in the room using thermal heat recognition, adjusting the temperature and airflow pattern for optimal comfort. This helps the Black Diamond Smart Series do more than simply save energy, it also enables a new level of truly personalised comfort to be achieved. Thermal Scan Technology The 3D i-See Sensor continually takes a thermal scan of the room, dividing it into 752 three-dimensional zones and measuring the temperature in each zone to detect exactly where people are in a room. Independently Controlled Dual Split Vane Airflow Intuitively Adjusts the Airflow Direction to Where it’s Needed The 3D i-See Sensor works in conjunction with the Dual Split Vanes to provide heating or cooling to where it is needed most. As a result, it can save energy by not heating or cooling areas that don’t require it. Whether you prefer direct, indirect or evenly distributed airflow, the 3D i-See Sensor and Dual Split Vanes provide the ultimate in customisable airflow. You'll Never Feel Cold The 3D i-See Sensor can recognise movement of an individual in a room and subsequently direct the airflow with the Dual Split Vanes; so they continue feeling warm no matter where they have moved to in the room. Comfort for All With Multiple Airflow Directions The 3D i-See Sensor can identify multiple people present in the room and adjust the Dual Split Vanes to direct heating or cooling evenly throughout; so everybody feels comfortable in the room. Even Airflow – Airflow Only Where You Need It With Even Airflow Mode, the 3D i-See Sensor memorises people’s movements and furniture positions, efficiently distributing airflow only to where it is needed. You always feel warm and comfortable as the direct heat follows you as you move around the room. Only one occupant feels direct heat. With Dual Split Vanes both occupants feel direct heat. 8 sensors measure while moving left to right 752 three-dimensional zones 8 x 94 areas
Energy Saving No Occupancy Modes The 3D i-See Sensor detects whether or not there are people in the room, and automatically switches to one of the No Occupancy Modes, as set by the user. In No Occupancy Energy Saving Mode when no one is in the room, the unit automatically reduces power consumption by approximately 10% after 10 minutes, and 20% after 60 minutes. In No Occupancy Auto-Off Mode, when no one is in the room, the unit turns off automatically. Advanced Plasma Quad Plus Filtration The advanced Plasma Quad Plus Filtration System, featuring high-performance two stage plasma technology, filters the air to clean away viruses such as Covid-19* as well as smells, dust, moulds and other common household allergens. The Two Stage Plasma Quad Plus Filter works like an electrical curtain, using an electrical discharge to catch and neutralise even microscopically small particles in the air. In fact, it can even capture PM2.5 particles (that's up to 30 times smaller than the width of a human hair!). Independent test results confirm that the Plasma Quad Filtration System achieves extremely high reduction results in the removal of allergen, mould, bacteria and airborne contaminants in the room. Providing up to 98.8% effectiveness of removing airborne Covid-19* particles too, it’s the ultimate peace of mind for ensuring a healthier, cleaner living environment. Superior Energy Efficiency Black Diamond Smart Series Heat Pumps are some of the most energy efficient heat pumps available in New Zealand. This high energy efficiency is achieved by incorporating a large, high-density heat exchanger, an advanced high-efficiency fan motor and a next-generation compressor using the latest in super efficient R32 refrigerant. LN Black Diamond Smart Series Bacteria Airborne Contaminants Moulds Allergens Micro Particles Dust The 3D i-See Sensor continuously scans the room for occupants. In Energy Saving Mode – power is reduced when you leave the room. In Auto-Off Mode – unit switches off when you leave the room. FILTRATION * PQC Electrode Collection Plate, Test Chamber Lab – Test No. 20KB070569, Microbial Testing Laboratory Kobe Testing Center Japan Textile Products Quality and Technology Center. ^ Such as Influenza A virus A/Aichi/2/68 (H3N2) - tested in a 25m2 room by Virus Research Center, Sendai Medical Center, National Hospital Organisation according to JEM 1467.
Dual Barrier Coating Maximises Efficient Performance The patented and world’s first Dual Barrier Coating from Mitsubishi Electric prevents dust and dirt from accumulating on the inner surface of the indoor unit; keeping your heat pump clean year-round. Keeping key internal components like the heat exchanger, fan and internal duct clean is important for both home comfort and efficiency. Not only does dust and dirt build-up typically create unpleasant odours, it also forces a heat pump to work harder, which can result in significantly impaired energy efficiency. Dual Barrier Coating prevents dust and oil build-up on the interior of the heat pump for the ultimate in peace of mind, ease and comfort. More Environmentally Friendly R32 Refrigerant With a global warming potential that is 30% lower compared to older refrigerants such as R410A, next-generation R32 refrigerant has a much lower environmental impact. Furthermore, zero ozone depleting R32 is easier to reuse and recycle. Blue Fin Coating – Built to Withstand the Elements The heat exchanger of the outdoor unit has been treated with Blue Fin AntiCorrosion Treatment, slowing the corrosion process caused by salt and sulphur in the air especially in coastal and high sulphur areas. Quiet Operation Black Diamond Smart indoor units feature Silent Mode – a fan speed setting that provides quiet operation as low as 19dBA* so you will feel the warmth, not hear it. 7-Day Programmable Controller All Black Diamond Smart Series Heat Pumps feature a built-in weekly timer, allowing you to program up to four time and temperature settings for each day of the week. You can now return to comfort without having to manually adjust the temperature. Perfect for anyone with a busy lifestyle, the 7-Day Controller is a great way to regulate your energy usage without compromising on comfort. Built-in Wi-Fi Control Energy Monitoring With Built-in Wi-Fi Control you can pre-heat or cool a room no matter where you are. On the way home, running late, coming home early, or even when you're in a different country, with Wi-Fi Control you'll always arrive home to total comfort. The intuitive app also features Energy Monitoring, allowing you to track indicative energy use so you can make more energy efficient choices when heating and cooling your space. Dimensions (WxDxH): 890 x 233 x 307mm MSZ-LN25VG2V/B/R** Heating Capacity: 3.2 kW | Cooling Capacity: 2.5 kW MSZ-LN35VG2V/B/R** Heating Capacity: 4.0 kW | Cooling Capacity: 3.5 kW MSZ-LN50VG3V/B/R** Heating Capacity: 6.0 kW | Cooling Capacity: 5.0 kW MSZ-LN60VG3V/B/R Heating Capacity: 6.8 kW | Cooling Capacity: 6.1 kW ** HyperCore option available. * LN 25/35 indoor sound level on the lowest fan setting. Black Diamond from 19dBA*
ZERL = Zoned Energy Rating Label EER = Energy Efficiency Ratio COP = Coefficient of Performance AEER = Annual Energy Efficiency Ratio ACOP = Annual Coefficient of Performance SPL = Sound Pressure Level ¹ SHi = Super High- ² Low–SHi = Low–Medium–High–Super High ³ SPL measured under rated operating frequency * Indoor Sound Levels rated at lowest fan speed. † Maximum length is inclusive of height differential i.e. (20/12) means the pipe can be 12m high and 8m across for a total length of 20m. ‡ Avge/Hot are Australia only. Rating Conditions (AS / NZS 3823). Cooling: Indoor: 27°C DB, 19°C WB. Outdoor: 35°C DB. Heating: Indoor: 20°C DB Outdoor: 7°C DB, 6°C WB. PUBLISHED May 2025 For more information please visit our website or call our Customer Service Team. www.mitsubishi-electric.co.nz | 0800 784 382 Learn more about the Black Diamond Smart Series LN Black Diamond Smart Series Specifications QUICK GLANCE TYPE High Wall System SERIES LN Black Diamond Smart Series LN Black Diamond Smart Series with HyperCore MODEL MSZ-LN25 MSZ-LN35 MSZ-LN50 MSZ-LN60 MSZ-LN25HZ MSZ-LN35HZ MSZ-LN50HZ REFRIGERANT R32 INDOOR UNIT MSZ-LN25VG2 MSZ-LN35VG2 MSZ-LN50VG3 MSZ-LN60VG3 MSZ-LN25VG2 MSZ-LN35VG2 MSZ-LN50VG3 OUTDOOR UNIT MUZ-LN25VG2 MUZ-LN35VG2 MUZ-LN50VG3 MUZ-LN60VG2 MUZ-LN25VGHZ2 MUZ-LN35VGHZ2 MUZ-LN50VGHZ2 COOL 2.5kW 5.10 EER 19 dBA* 3.5kW 4.27 EER 19 dBA* 5.0kW 3.62 EER 27 dBA* 6.1kW 3.53 EER 29 dBA* 2.5kW 5.10 EER 19 dBA* 3.5kW 4.27 EER 19 dBA* 5.0kW 3.62 EER 27 dBA* HEAT 3.2kW 5.33 COP 19 dBA* 4.0kW 4.88 COP 19 dBA* 6.0kW 4.05 COP 25 dBA* 6.8kW 3.78 COP 29 dBA* 3.2kW 5.33 COP 19 dBA* 4.0kW 4.88 COP 19 dBA* 6.0kW 4.00 COP 25 dBA* ZERL STAR RATINGS (NZ) Cold Area 5.0 3.0 4.5 3.0 3.5 2.0 3.0 2.0 5.0 3.0 4.0 3.0 3.5 2.5 Avge Area‡ 4.5 3.5 4.0 3.5 3.5 2.5 3.0 2.5 4.5 3.5 4.0 3.5 3.0 2.5 Hot Area‡ 5.0 4.0 4.5 3.5 3.5 3.0 3.0 3.0 5.0 4.0 4.0 3.5 3.5 3.0 COOL Capacity Rated [kW] 2.5 3.5 5.0 6.1 2.5 3.5 5.0 Min-Max [kW] 1.0-3.5 0.8 -4.0 1.0 -6.0 1.4 - 6.9 0.8 - 3.5 0.8 - 4.0 1.4 - 5.8 Total Input Rated [kW] 0.49 0.82 1.38 1.73 0.49 0.82 1.38 EER/AEER 5.10 / 5.07 4.27 / 4.25 3.62 / 3.61 3.53 / 3.52 5.10 / 5.07 4.27 / 4.25 3.62 / 3.61 Indoor Sound Level Quiet [dBA] 19 19 27 29 19 19 27 Low-SHi2 [dBA] 23-29-36-42 24-29-36-43 31-35-39-46 37-41-45-49 23-29-36-42 24-29-36-43 31-35-39-46 Running Current (Rated) [A] 2.7 3.8 6.3 7.8 2.5 3.8 6.3 Air Volume In (SHi1) [L/s] 207 217 232 262 207 217 232 HEAT Capacity Rated [kW] 3.2 4.0 6.0 6.8 3.2 4.0 6.0 Min-Max [kW] 0.7 - 5.4 0.9 - 6.3 1.0 - 8.2 1.8–9.8 0.8–6.3 0.9–7.0 1.8–9.0 @-15°C [kW] - - - - 3.2 4.0 6.0 Total Input Rated [kW] 0.6 0.82 1.48 1.80 0.60 0.82 1.50 COP / ACOP 5.33 / 5.30 4.88 / 4.86 4.05 / 4.04 3.78 / 3.77 5.33 / 5.30 4.88 / 4.86 4.00 / 3.99 Indoor Sound Level Quiet [dBA] 19 19 25 29 19 19 25 Low-SHi2 [dBA] 24-29-38-45 24-29-38-45 29-35-43-47 37-41-45-49 24-29-38-45 24-29-38-45 29-35-43-47 Running Current (Rated) [A] 3.4 3.8 6.8 7.9 3.0 3.8 6.8 Air Volume In (SHi1) [L/s] 232 232 255 263 232 232 255 Controller Standard Premium LN 7-Day Programmable Controller and Wi-Fi Control Optional Wired 7-Day Timer Optional: PAR Controller (Interface Required) Wi-Fi Built-In with Energy Monitoring Power Supply (Powered From Outdoor Unit) 230 V / Single Phase / 50 Hz Maximum Current [A] 7.1 9.9 13.8 15.2 9.9 10.5 15.1 Indoor Dimensions (WxDxH) [mm] 890 x 233 x 307 890 x 233 x 307 Weight [kg] 15.5 15.5 16.0 16.0 15.5 16.0 Outdoor Dimensions (WxDxH) [mm] 800 x 285 x 550 800 x 285 x 550 800 x 285 x 714 840 x 330 x 880 800 x 285 x 550 840 x 330 x 880 Weight [kg] 33 34 40 53 34 55 Sound Level - SPL³/Power (Cooling-Heating) [dBA] 46-49 / 60-61 49-50 / 61-62 51-54 / 64-66 55-55 / 65-69 46-49 / 60-61 49-50 / 61-62 51-55 / 64-66 Piping Diameter (Liquid/Gas) [mm] 6.35 / 9.52 6.35 / 9.52 6.35 / 9.52 6.35 / 12.7 6.35 / 9.52 6.35 / 9.52 6.35 / 9.52 Max. Length/Height† [m] 20 / 12 20 / 12 30 / 12 30 / 15 20 / 12 20 / 12 30 / 15 Chargeless Piping Length [m] 10 10 15 7 10 10 7 Operation Range Outdoor Cooling [˚C] -10 /+46 -10 /+46 -10 /+46 -10 /+46 Heating [˚C] -15 /+24 -25 /+24 -25 /+24 -25 /+24 Indoor Unit Colour Black Diamond / Red Diamond / White Diamond
