Functionality, Versatility and Comfort for Every Environment Commercial Air Conditioning Systems The Next Generation of R32 Commercial Solutions is Here
The Mr Slim R32 range features the latest in super-efficient and more environmentally friendly R32 refrigerant, enabling the integration of more cost savings into any HVAC design. Featuring a GWP of just 675, R32 refrigerant is highly energy efficient and with a volumetric capacity that is around 20% higher compared to R410A, system refrigerant volumes are significantly lower. Furthermore our R32 Mr Slim models blend a host of outstanding features with a premium quality, sophisticated design. Offering high efficiencies, advanced control options and extended pipe runs, the range is extremely flexible and cost effective. The next generation of R32 Mr Slim Range is here! Benefits of R32 compared to R410A 66% lower GWP of 675 More environmentally friendly 20% less refrigerant volume requirement Overall higher system efficiency
Product Line-Up....................................................................................... 2 PEAD Series ............................................................... 4 Ducted System PEA Splittable Series ................................................. 6 Ducted System PEA Series ................................................................. 8 Ducted System SEZ Series ............................................................... 10 Ceiling Concealed System PKA Series ................................................................ 11 High Wall System MLZ SlimFit Series ................................................... 12 One-Way Ceiling Cassette System SLZ Series ................................................................ 13 Compact Ceiling Cassette System PLA Series ................................................................ 14 Ceiling Cassette System PCA Series ............................................................... 16 Under-Ceiling System Controllers.............................................................................................. 18 Advanced Feature – 3D i-See Sensor..................................................... 19 Outdoor Unit Specifications ................................................................... 20 Comfort takes on new meaning with Mitsubishi Electric Power Inverter Systems. Selected worldwide for their space-saving design, quiet operation, energy efficiency and durability, there is a wide variety of indoor unit designs and outdoor unit capacities ensuring the flexibility to meet the most challenging of heating and cooling needs, whether domestic or commercial. 1
2.5kW 3.5kW 5.0kW 6.0kW 7.1kW R32 R32 R32 R32 R32 Ducted PEAD Series PEAD-M50JAA PEAD-M60JAA PEAD-M71JAA PEA Splittable Series PEA Series Ceiling Concealed SEZ Series SEZ-M35DA SEZ-M50DA SEZ-M60DA SEZ-M71DA High Wall PKA Series Ceiling Cassette MLZ Series MLZ-KP25VG MLZ-KP35VG MLZ-KP50VG SLZ Series SLZ-M25FA SLZ-M35FA SLZ-M50FA SLZ-M60FA PLA Series PLA-M71EA2 Under Ceiling PCA Series PCA-M50KA2 PCA-M60KA2 PCA-M71KA2 Outdoor Unit SUZ-M25VAD SUZ-M35VAD SUZ-M50VAD SUZ-M60VAD SUZ-M71VAD Product Line-Up 2
7.1kW 10.0kW 12.5kW 14.0kW 16.0kW 18.0kW 20.0kW 24.5kW R32 R32 R32 R32 R32 R32 R32 R32 PEAD-M71JAA PEAD-M100JAA PEAD-M125JAA PEAD-M140JAA PEA-M100HAA PEA-M125HAA PEA-M140HAA PEA-M160HAA PEA-M180LAA PEA-M200LAA PEA-M250LAA PEA-M100GAA PEA-M125GAA PEA-M140GAA PKA-M71KAL2 PKA-M100KAL2*1 PLA-M71EA2 PLA-M100EA2 PLA-M125EA2 PLA-M140EA2*2 PCA-M71KA2 PCA-M71HA2 PCA-M100KA2 PCA-M125KA2 PCA-M140KA2*2 PUZ-ZM71VHA2 PUZ-ZM100VKA2 (Deluxe) PUZ-M100VKA (Standard)*1 PUZ-ZM125VKA2 (Deluxe) PUZ-M125VKA (Standard) PUZ-ZM140VKA2 (Deluxe) PUZ-M140VKA (Standard)*2 PUZ-ZM160VKA PUZ-ZM180VKA PUZ-ZM200YKA PUZ-ZM250YKA *1 PUZ-M100VKA (Standard) is not compatible with PKA-M100KAL2 *2 PUZ-M140VKA (Standard) is not compatible with PLA-M140 Cassettes or PCA-M140. 3
Next-Generation R32 Technology With a global warming potential that is 30% lower compared to older refrigerants such as R410A, next-generation R32 refrigerant has a much lower environmental impact. Furthermore, zero ozone depleting R32 is easier to reuse and recycle. Compact Indoor Units The height of the PEAD Range has been unified to 250mm making installation possible in low ceilings with minimal clearance space. It has variable airflow settings to ensure the best operation to match virtually all room layouts. Wide Selection of Fan Speeds and External Static Pressure All PEAD models incorporate five-stage external static pressure conversions and three fan speed selections, offering the ultimate in comfort diversity. With a wide range of adjustable static pressures (35-125Pa), PEAD Series units are applicable to a wide range of building types and applications. Standard or Deluxe Outdoor Units The Standard Range of our ducted systems are the ideal economical solution for buildings or homes where extended pipe runs are not necessary. The Deluxe Outdoor Unit offers longer pipe runs, slightly lower Sound Pressure Levels and extended guaranteed heating down to -20°C. Optional Lossnay Fresh Air Ventilation The Mitsubishi Electric Lossnay Ventilation system can be integrated with a Ducted Heat Pump System. By recovering energy from stale air to pre-heat or pre-cool incoming fresh air, Lossnay reduces the amount of additional heating or cooling required. This results in increased energy savings while ventilating your home to remove stale air and combat condensation. Combine both seamlessly through the Wi-Fi Control App for the ultimate visibility and control*1. Optional Wi-Fi Control! Never Return to a Cold Home Again With optional Wi-Fi Control you can pre-heat or cool a room no matter where you are. On the way home, running late, coming home early, or even when you’re in a different country, with Wi-Fi Control you’ll always arrive home to total comfort. Wi-Fi Control is Amazon Alexa and Google Home enabled so you can take your comfort to the next level and enjoy hands-free heat pump control. Optional Zone Controller The optional Zone Controller brings intuitive yet simple control to a whole new level, with the ability to control up to eight zones, automatic unloading/ramping and energy saving sensor functions. The thin, low-profile, ceiling-concealed PEAD indoor units are the perfect answer for air conditioning requirements of buildings with minimum ceiling installation space and wide-ranging external static pressure. Energy-saving efficiency has been improved, thereby reducing electricity consumption, and contributing to further reductions in operating cost. PEAD Series Ducted System *1 Each unit requires its own Wi-Fi Interface to enable Wi-Fi Interlock Control. Please refer to Page 9 for more information. 4
Specifications: PEAD Ducted Series Refrigerant R32 Indoor Unit PEAD-M50JAA PEAD-M60JAA PEAD-M71JAA Outdoor Unit (Standard, Deluxe) SUZ-M50VAD SUZ-M60VAD SUZ-M71VAD PUZ-ZM71VHA2 Function Cooling Heating Cooling Heating Cooling Heating Cooling Heating Capacity (min.–max.) (kW) 5.0 (2.3-6.2) 6.0 (1.7-7.4) 6.0 (2.3-6.5) 7.0 (2.8-8.0) 7.1 (2.8-8.1) 8.0 (2.6-10.2) 7.1 (3.3-8.1) 8.0 (3.5-10.2) Power Input (kW) 1.33 1.44 1.72 1.85 1.98 2.00 1.85 1.93 Rated EER/COP 3.75 4.16 3.48 3.78 3.58 4.00 3.83 4.14 Rated AEER/ACOP 3.70 4.09 3.43 3.72 3.53 3.93 3.69 3.93 Power Supply Single-Phase, 50Hz, 230V Airflow (Lo–Hi) m3/min 12 - 14.5 - 17 14.5 - 18 - 21 17.5 - 21 - 25 17.5 - 21 - 25 L/S 200 - 242 - 283 242 - 300 - 350 292 - 350 - 417 292 - 350 - 417 Indoor Sound Pressure Level (dB) 30 - 35 - 39 30 - 32 - 36 30 - 33 - 38 30 - 34 - 39 External Static Pressure Pa 35 / 50 / 70 / 100 / 125 Indoor Unit Dimensions Height (mm) 250 250 250 Width (mm) 900 1,100 1,100 Depth (mm) 732 732 732 Indoor Unit Weight (kg) 26 29 30 Refrigerant Piping Max. Length/Height 30 / 30 50 / 30 Operation Range Outdoor Cooling (°C) -5(-15*2) ~ 52 Heating (°C) -10 ~ 24 -20 ~ 21 *2 With optional air protection guide. Refer to page 20 for outdoor specifications. Specifications: PEAD Ducted Series Refrigerant R32 Indoor Unit PEAD-M100JAA PEAD-M125JAA PEAD-M140JAA Outdoor Unit PUZ-M100VKA PUZ-ZM100VKA2 PUZ-M125VKA PUZ-ZM125VKA2 PUZ-M140VKA PUZ-ZM140VKA2 Function Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating Capacity (min.–max.) (kW) 10.0 (4.0-10.6) 12.5 (2.8-12.5) 10.0 (4.9-11.4) 11.2 (4.5-14.0) 12.0 (6.0-13.5) 14.0 (4.1-15.5) 12.5 (5.5-14.0) 14.0 (5.0-16.0) 14.0 (6.2- 15.3) 16.0 (5.7-18.0) 14.0 (6.2-15.3) 16.0 (5.7-18.0) Power Input (kW) 3.06 3.35 2.67 2.80 3.83 3.68 3.66 3.52 4.40 4.30 4.37 4.18 Rated EER/COP 3.26 3.73 3.74 4.00 3.13 3.80 3.41 3.97 3.18 3.72 3.20 3.82 Rated AEER/ACOP 3.13 3.59 3.61 3.86 3.03 3.67 3.32 3.86 3.09 3.61 3.13 3.73 Power Supply Single-Phase, 50Hz, 230V Airflow (Lo–Hi) m3/min 24 - 29 - 34 29.5 - 35.5 - 42 32 - 39 - 46 L/S 400 - 483 - 567 492 - 592 - 700 533 - 650 - 767 Indoor Sound Pressure Level (dB) 33 - 38 - 42 36 - 40 - 44 40 - 44 - 49 External Static Pressure Pa 35 / 50 / 70 / 100 / 125 Indoor Unit Dimensions Height (mm) 250 250 Width (mm) 1,400 1,600 Depth (mm) 732 732 Indoor Unit Weight (kg) 39 40 44 Refrigerant Piping Max. Length/Height 55 / 30 75 / 30 55 / 30 75 / 30 55 / 30 75 / 30 Operation Range Outdoor Cooling (°C) -5 (-15*2) ~ 46 -5(-15*2) ~ 52 -5 (-15*2) ~ 46 -5(-15*2) ~ 52 -5 (-15*2) ~ 46 -5(-15*2) ~ 52 Heating (°C) -15 ~ 21 -20 ~ 21 -15 ~ 21 -20 ~ 21 -15 ~ 21 -20 ~ 21 *2 With optional air protection guide. Refer to page 20 for outdoor specifications. 5
Next-Generation R32 Technology With a global warming potential that is 30% lower compared to older refrigerants such as R410A, next-generation R32 refrigerant has a much lower environmental impact. Furthermore, zero ozone depleting R32 is easier to reuse and recycle. Flexible Install Options The PEA indoor unit can be separated into the fan deck and heat exchange for ease of transportation into the roof space. Its two-piece construction makes the PEA Series an ideal solution for re-modelling of existing homes into roof trusses. Flexible Duct Design with High Static Pressure Fan With a range of external static pressure settings from 50Pa-150Pa (PEA-M HAA) and 75Pa-250Pa (PEA-M LAA) the PEA Splittable Series offers complete flexibility in duct design. The increased variation in airflow options ensures operation that best matches virtually all room layouts. Standard or Deluxe Outdoor Units The PEA Splittable Ducted range offers up to 10 possible system outdoor combinations, giving you maximum design flexibility to efficiently heat and cool large residences or offices. The standard range of our ducted systems are the ideal economical solution for buildings or homes where extended pipe runs are not necessary. The deluxe outdoor unit offers longer pipe runs, slightly lower sound pressure levels and extended guaranteed heating down to -20°C. Optional Lossnay Fresh Air Ventilation The Mitsubishi Electric Lossnay Ventilation system can be integrated with a Ducted Heat Pump System. By recovering energy from stale air to pre-heat or pre-cool incoming fresh air, Lossnay reduces the amount of additional heating or cooling required. This results in increased energy savings while ventilating your home to remove stale air and combat condensation. Combine both seamlessly through the Wi-Fi Control App for the ultimate visibility and control*1. One of New Zealand’s Largest Single-Phase Ducted Systems The new PEA-M180LAA removes the need for costly 3-phase power building upgrades. The single-phase 18kW ducted system ensures optimal comfort without the hassle or expense of additional electrical modifications. Optional Wi-Fi Control! Never Return to a Cold Home Again With optional Wi-Fi Control you can pre-heat or cool a room no matter where you are. On the way home, running late, coming home early, or even when you’re in a different country, with Wi-Fi Control you’ll always arrive home to total comfort. Wi-Fi Control is Amazon Alexa and Google Home enabled so you can take your comfort to the next level and enjoy hands-free heat pump control. Optional Zone Controller The optional Zone Controller brings intuitive yet simple control to a whole new level, with the ability to control up to eight zones, automatic unloading/ramping and energy saving sensor functions. Unified Outdoor Unit Design Designed to seamlessly integrate with your space, the PUZ Deluxe range of outdoor units are all uniform in size. From 10kW all the way up to 25kW, these compact outdoor units can also easily fit inside a Heat Pump Cover, ensuring they not only remain hidden from view but also compliment the aesthetic harmony of your architecture and building. The PEA Splittable Ducted System is the perfect answer for unobtrusive heating and cooling in both new homes and existing homes, thanks to its ability to be split in two during transportation for flexible installation into a roof space. PEA Splittable Series Ducted System *1 Each unit requires its own Wi-Fi Interface to enable Wi-Fi Interlock Control. Please refer to Page 9 for more information. 6
Identical Dimensions PUZ-ZM Deluxe Range Outdoor Units Specifications: PEA-HAA Ducted Series Refrigerant R32 Indoor Unit PEA-M100HAA PEA-M125HAA PEA-M140HAA PEA-M160HAA Outdoor Unit (Standard, Deluxe) PUZ-M100VKA PUZ-ZM100VKA2 PUZ-M125VKA PUZ-ZM125VKA2 PUZ-M140VKA PUZ-ZM140VKA2 PUZ-ZM160VKA Function Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating Capacity (min.–max.) (kW) 10.0 (4.010.6) 12.5 (2.812.5) 10.0 (4.911.4) 11.2 (4.514.0) 12.0 (6.013.5) 14.0 (4.115.5) 12.5 (5.514.0) 14.0 (5.016.0) 14.0 (6.215.3) 16.0 (5.718.0) 14.0 (6.215.3) 16.0 (5.718.0) 16.0 (4.717.0) 18.0 (5.420.0) Power Input (kW) 3.02 3.24 2.65 2.71 3.78 3.44 3.50 3.40 4.24 3.85 4.19 3.97 4.95 4.58 Rated EER/COP 3.31 3.85 3.77 4.13 3.17 4.06 3.57 4.11 3.30 4.15 3.34 4.03 3.23 3.93 Rated AEER/ACOP 3.21 3.75 3.63 3.98 3.10 3.96 3.47 3.99 3.23 4.06 3.26 3.93 3.16 3.84 Power Supply 230V, Single-phase, 50Hz Airflow (Lo–Hi) m3/min 30-34-38-42 42-48-54-60 L/S 500-567-633-700 700-800-900-1000 Indoor Sound Pressure Level (dB) 29-32-36-38 35-38-42-45 External Static Pressure (Pa) 50 / 100 / 150 Dimensions Height (mm) 380*2 Width (mm) 1405*2 Depth (mm) 900*2 Indoor Unit Weight (kg) 63 66 Refrigerant Piping Max. Length/Height 55 / 30 75 / 30 55 / 30 75 / 30 55 / 30 75 / 30 Operation Range Outdoor Cooling (°C) -5(-15*3) ~ 46 -5(-15*3) ~ 52 -5(-15*3) ~ 46 -5(-15*3) ~ 52 -5(-15*3) ~ 46 -5(-15*3) ~ 52 Heating (°C) -15 ~ 21 -20 ~ 21 -15 ~ 21 -20 ~ 21 -15 ~ 21 -20 ~ 21 *2 When fully installed the PEA-M HAA should be assembled together in one-piece. Any gaps between the fan deck section and heat exchanger at final install will result in significant pressure loss. *3 With optional air protection guide. Refer to page 20 for outdoor specifications. Specifications: PEA-LAA Ducted Series Refrigerant R32 Indoor Unit PEA-M180LAA PEA-M200LAA PEA-M250LAA Outdoor Unit (Standard, Deluxe) PUZ-ZM180VKA PUZ-ZM200YKA PUZ-ZM250YKA Function Cooling Heating Cooling Heating Cooling Heating Capacity (min.–max.) (kW) 18.0 (4.9-20.0) 20.0 (5.4-22.4) 20.0 (4.9-22.4) 22.4 (5.7-25.0) 24.5 (6.3-25.0) 28.0 (7.9-29.0) Power Input (kW) 5.52 5.10 6.40 5.90 8.00 7.50 Rated EER/COP 3.26 3.92 3.12 3.79 3.06 3.73 Rated AEER/ACOP 3.20 3.84 3.07 3.72 3.02 3.67 Power Supply 230V, Single-phase, 50Hz 400V, Three-phase, 50Hz Airflow (Lo–Hi) m3/min 36-50-61-72 42-58-72-84 L/S 600-833-1017-1200 700-967-1200-1400 Indoor Sound Pressure Level (dB) 30-37.5-42-46 32.5-40-45.5-48.5 External Static Pressure (Pa) 75 / 100 / 150 / 200 / 250 Dimensions Height (mm) 470*4 Width (mm) 1370*4 Depth (mm) 1120*4 Indoor Unit Weight (kg) 88 Refrigerant Piping Max. Length/Height 75 / 30 100 / 30 Operation Range Outdoor Cooling (°C) -5(-15*3) ~ 52 Heating (°C) -20 ~ 21 *3 With optional air protection guide. *4 When fully installed the PEA-M LAA should be assembled together in one-piece. Any gaps between the fan deck section and heat exchanger at final install will result in significant pressure loss. Refer to page 20 for outdoor specifications. PUZ-ZM100VKA PUZ-ZM125VKA PUZ-ZM140VKA PUZ-ZM160VKA PUZ-ZM180VKA PUZ-ZM200VKA PUZ-ZM250VKA 7
Flexible Duct Design Enables Use of High‑Pressure Static Fan With a maximum 150Pa external static high-pressure setting, PEA Series models offer complete flexibility in duct design. The increased variation in airflow options ensures operation that best matches virtually all room layouts. Versatile and Easy Installation Options PEA Series models offer both versatility and ease of installation/ application; for example, it is possible to adjust the distance between the air-intake and airoutlet vents to create the optimal airflow configuration. Next-Generation R32 Technology Featuring the latest in super-efficient and more environmentally friendly R32 refrigerant with 30% lower global warming potential than R410A, R32 offers a significantly reduced environmental impact, zero ozone depletion, and improved recyclability. Blending advanced efficiencies, flexible control options, extended pipe runs, and premium design, these systems deliver high performance with exceptional installation versatility and value. Standard or Deluxe Outdoor Units The Standard Range of our ducted systems are the ideal economical solution for buildings or homes where extended pipe runs are not necessary. The Deluxe Outdoor Unit offers longer pipe runs, slightly lower Sound Pressure Levels and extended guaranteed heating down to -20°C. Optional Lossnay Fresh Air Ventilation The Mitsubishi Electric Lossnay Ventilation system can be integrated with a Ducted Heat Pump System. By recovering energy from stale air to pre-heat or pre-cool incoming fresh air, Lossnay reduces the amount of additional heating or cooling required. This results in increased energy savings while ventilating your home to remove stale air and combat condensation. Combine both seamlessly through the Wi-Fi Control App for the ultimate visibility and control*1. Optional Wi-Fi Control! Never Return to a Cold Home Again With optional Wi-Fi Control you can pre-heat or cool a room no matter where you are. On the way home, running late, coming home early, or even when you’re in a different country, with Wi-Fi Control you’ll always arrive home to total comfort. Wi-Fi Control is Amazon Alexa and Google Home enabled so you can take your comfort to the next level and enjoy hands-free heat pump control. The PEA Series’ high static airflow allows air to be directed to different areas of your home or office with ease, ideal for heating or cooling a number of rooms at once. With an aesthetically pleasing ceiling installation and vast line-up of performance functions, the PEA Series provides the ultimate in comfort. Long rectangular room Room with fixed ceiling fixtures L-shaped room PEA Series PEA-M100~140GAA Ducted System *1 Each unit requires its own Wi-Fi Interface to enable Wi-Fi Interlock Control. Please refer to Page 9 for more information. 8
Specifications: PEA-GAA Ducted Series Refrigerant R32 Indoor Unit PEA-M100GAA PEA-M125GAA PEA-M140GAA Outdoor Unit (Standard, Deluxe) PUZ-M100VKA PUZ-ZM100VKA2 PUZ-M125VKA PUZ-ZM125VKA2 PUZ-M140VKA PUZ-ZM140VKA2 Function Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating Capacity (min.–max.) (kW) 10.0 (4.0-10.6) 12.5 (2.8-12.5) 10.0 (4.9-11.4) 11.2 (4.5-14.0) 12.0 (6.0-13.5) 14.0 (4.1-15.5) 12.5 (5.5-14.0) 14.0 (5.0-16.0) 14.0 (6.2-15.3) 16.0 (5.7-18.0) 14.0 (6.2-15.3) 16.0 (5.7-18.0) Power Input (kW) 3.08 3.36 2.39 2.51 3.81 3.54 3.52 3.27 4.22 4.20 4.10 3.90 Rated EER/COP 3.24 3.72 4.18 4.46 3.14 3.95 3.55 4.28 3.31 3.80 3.41 4.10 Rated AEER/ACOP 3.12 3.58 4.01 4.29 3.04 3.81 3.45 4.15 3.22 3.69 3.33 3.99 Power Supply 230V, Single-phase, 50Hz Airflow (Lo–Hi) m3/min 34-42 48-60 L/S 567-700 800-1000 Indoor Sound Pressure Level (dB) 33-38-42 39-42 42-45 External Static Pressure (Pa) 50 / 100 / 150 Dimensions Height (mm) 400 Width (mm) 1,400 Depth (mm) 634 Indoor Unit Weight (kg) 63 Refrigerant Piping Max. Length/Height 55 / 30 75 / 30 55 / 30 75 / 30 55 / 30 75 / 30 Operation Range Outdoor Cooling (°C) -5(-15*2) ~ 46 -5(-15*2) ~ 52 -5(-15*2) ~ 46 -5(-15*2) ~ 52 -5(-15*2) ~ 46 -5(-15*2) ~ 52 Heating (°C) -15 ~ 21 -20 ~ 21 -15 ~ 21 -20 ~ 21 -15 ~ 21 -20 ~ 21 *2 With optional air protection guide. Refer to page 20 for outdoor specifications. Optional Zone Controller The optional Zone Controller brings intuitive yet simple control to a whole new level, with the ability to control up to eight zones, automatic unloading/ramping and energy saving sensor functions. Optional Wi-Fi Interlock for Total Home Control Seamlessly combine a Mitsubishi Electric Mr Slim Ducted Heat Pump and Lossnay Heat Recovery Ventilation System through the Wi-Fi Control App for the ultimate visibility and control. Because the Ducted Heat Pump needs to be in fan, heating or cooling mode for the connected Lossnay system to operate, you can now choose from two innovative modes to customise the climate control setup. Use the “Power Interlock” mode, to enjoy set and forget convenience. In this mode, both systems will always automatically activate together no matter which system you initially turn on. Opt for “Fresh Air Fan Interlock” mode to prioritise fresh air circulation; regardless of whether the ducted system is turned on. In this mode, the Lossnay System will override a ducted system that is turned off and automatically activate the system’s Fan Mode. As a result fresh air continues to efficiently circulate throughout the building. Note: Each unit requires its own Wi-Fi Interface to enable Wi-Fi Interlock Control. 9
Compact Design Ceiling concealed and a slim 200mm in height, the SEZ Series is ideal for tight installation spaces. Quiet Comfort The SEZ Series offers whisper quiet operation, starting at a hushed 23dBA*1. Air Cleaning Filter This built-in filter removes dust and other irritating particles, keeping the air clean at all times. Maintenance is as simple as vacuuming. Easy Installation The SEZ Series’ lightweight design and low unit height makes for an easier and more convenient installation. The SEZ Series is conveniently hidden in the ceiling cavity with only the grilles visible. Compact, whisper quiet and highly efficient, these concealed units fit easily and discreetly into rooms with lowered or bulkhead ceilings. SEZ Series Specifications: SEZ Ceiling Concealed Series Refrigerant R32 Indoor Unit SEZ-M35DA SEZ-M50DA SEZ-M60DA SEZ-M71DA Outdoor Unit SUZ-M35VAD SUZ-M50VAD SUZ-M60VAD SUZ-M71VAD Function Cooling Heating Cooling Heating Cooling Heating Cooling Heating Capacity (min.–max.) (kW) 3.5 (1.5-4.0) 4.0 (1.3-5.0) 5.0 (2.3-6.3) 6.0 (1.7-7.2) 6.0 (2.3-6.5) 7.0 (2.5-8.0) 7.1 (2.8-8.3) 8.0 (2.6-10.4) Power Input (kW) 1.01 1.11 1.40 1.66 1.73 2.00 2.14 2.22 Rated EER/COP 3.46 3.60 3.57 3.61 3.46 3.50 3.31 3.60 Rated AEER/ACOP 3.39 3.53 3.51 3.57 3.41 3.45 3.27 3.55 Power Supply V: Single-phase, 50Hz, 230V Airflow (Lo–Mid–Hi) m3/min 7-9-11 10-12.5-15 12-15-18 12-16-20 L/S 117-150-183 167-208-250 200-250-300 200-267-333 External Static Pressure Pa 5 / 15 / 35 / 50 Sound Pressure Level (dB) 23-28-33 30-34-37 30-34-38 30-35-40 Dimensions Height (mm) 200 200 200 200 Width (mm) 990 990 1190 1190 Depth (mm) 700 700 700 700 Weight (kg) 21 22 25.5 25.5 Refrigerant Piping Max. Length/Height (m) 20 / 12 30 / 30 Refer to page 20 for outdoor specifications. Ceiling Concealed System *1 SEZ-M35 indoor sound level on lowest fan speed. 10
Suitable for Server Room Applications The PKA Series provides an economical split system solution for high sensible applications due to their larger coil size. As a result they are ideal for applications such as server rooms and laboratories where there is a need for sensible cooling. Increased Application Possibilities Utilising PUZ Deluxe Outdoor Units, the PKA Series boasts an extended pipe run of up to 75m*2 (up from 30m, offering up to 2.5 times the maximum piping length) compared to our M Series High Wall solutions. Quick Clean Grille The intake grille can easily slide out completely, allowing simple cleaning without any special tools; making it easy to clean in minutes by washing in water. Specifications: PKA High Wall Series Refrigerant R32 Indoor Unit PKA-M71KAL2 PKA-M100KAL2 Outdoor Unit PUZ-ZM71VHA2 PUZ-ZM100VKA2 Function Cooling Heating Cooling Heating Capacity (min.–max.) (kW) 7.1 (3.3-8.1) 8.0 (3.5-10.2) 10.0 (4.9-11.4) 11.2 (4.5-14.0) Power Input (kW) 1.86 2.12 2.81 3.10 Rated EER/COP 3.81 3.77 3.55 3.61 Rated AEER/ACOP 3.67 3.65 3.43 3.49 Power Supply V: Single-phase, 50Hz, 230V Airflow (Lo–Mid–Hi) m3/min 18-20-22 20-23-26 L/S 300-333-367 333-383-433 Sound Pressure Level (dB) 39-42-45 41-45-49 Dimensions Height (mm) 365 Width (mm) 1,170 Depth (mm) 295 Weight (kg) 21 Refrigerant Piping Max. Length/Height (m) 50 / 30 75 / 30 Refer to page 20 for outdoor specifications. The large capacity PKA Series is both elegant and compact. With greater placement options and high airflow, PKA Series units are ideal for light commercial use (i.e. offices, stores, and server rooms). Multiple Control Options With the addition of a separately sold wired remote controller and terminal block, the PKA Series can be upgraded to allow a wider range of weekly timer settings, suiting various installation sites. At the same time, the PKA Series can be upgraded with optional Wi-Fi Control, allowing users to select a control solution that suits their requirements, and optimize energy efficiency with smart scheduling and room control. Auto-Vane Shutter The vane closes automatically when the unit is not running, creating a sleek flat finish that is aesthetically pleasing. PKA Series High Wall System *2 Based on PUZ-ZM100 Outdoor Unit. PUZ-ZM71 Outdoor Unit has a 50m maximum piping length (1.6 times compared to our M Series High Wall solutions). 11
Slim Body Design MLZ SlimFit Series are designed with a slim body (only 185mm high), ensuring easy installation even when low ceiling cavities limit installation space e.g. within the interstitial space of multi-level dwellings. The need for ceiling cavity service space is also eliminated, further reducing the dimensions required for installation. Set Airflow According to Ceiling Height Dual-level airflow selection is engineered to accommodate specific ceiling heights. This is a key feature for adjusting airflow effectively when it is either too strong or too weak due to being mismatched with the height of the ceiling. MLZ SlimFit Series Auto Vane Control Outlet vanes can be moved left and right, and up and down using the remote controller. This improved airflow control feature solves the problem of draughts. Horizontal Airflow The new airflow control completely eliminates that uncomfortable draughty-feeling with the introduction of a horizontal airflow that spreads across the ceiling. The ideal airflow for offices and restaurants. Specifications: SlimFit MLZ One-Way Ceiling Cassette Series Refrigerant R32 Indoor Unit MLZ-KP25VG MLZ-KP35VG MLZ-KP50VG Outdoor Unit SUZ-M25VAD SUZ-M35VAD SUZ-M50VAD Function Cooling Heating Cooling Heating Cooling Heating Capacity (min.–max.) (kW) 2.5 (1.5-3.2) 3.2 (1.3-4.2) 3.5 (1.5-4.1) 4.1 (1.3-4.7) 5.0 (2.3-5.5) 6.0 (1.7-6.8) Power Input (kW) 0.59 0.79 0.90 1.13 1.37 1.83 Rated EER/COP 4.23 4.05 3.88 3.62 3.64 3.27 Rated AEER/ACOP 4.07 3.93 3.80 3.56 3.59 3.24 Power Supply Single-phase, 50Hz, 230V Airflow m3/min 6-7-8-8.5 6-7-8-9 6-7.5-8.5-9.5 6-7.5-8.5-10 6-8-9.5-11.5 6-8.5-10-12 L/S 100-120-133-147 100-117-137-153 100-122-140-157 100-128-147-165 100-138-163-190 100-147-172-197 Sound Pressure Level (dB) 27-31-34-38 26-29-34-37 27-32-36-40 26-32-36-40 29-36-41-47 26-37-42-48 Dimensions Height (mm) Unit: 185, Panel: 24 Width (mm) Unit: 1102, Panel: 1200 Depth (mm) Unit: 360, Panel: 424 Weight (indoor) (kg) Unit: 15.5, Panel: 3.5 Refrigerant Piping Max. Length/Height (m) 20 / 12 30 / 30 Refer to page 20 for outdoor specifications. Ceiling Cassette System The SlimFit MLZ One-Way Cassette Series offer a compact and streamlined ceiling-mounted solution for unobtrusive comfort. Featuring a new design combined with advanced airflow options, the Slimfit MLZ Series is ideal for both home and office applications. Up and Down Left and Right Only available when Econo Cool is set. Up and Down Left and Right Only available when Econo Cool is set. Capacity Class 25 35 50 Standard 2.4m 2.4m 2.4m High Ceiling 2.7m 2.7m 2.7m 12
Specifications: SLZ Compact Ceiling Cassette Series Refrigerant R32 Indoor Unit SLZ-M25FA SLZ-M35FA SLZ-M50FA SLZ-M60FA Outdoor Unit SUZ-M25VAD SUZ-M35VAD SUZ-M50VAD SUZ-M60VAD Function Cooling Heating Cooling Heating Cooling Heating Cooling Heating Capacity (min.–max.) (kW) 2.5 (1.5-3.5) 3.0 (1.3-4.1) 3.5 (1.5-4.0) 4.0 (1.3-5.0) 5.0 (2.3-5.5) 5.0 (1.7-5.5) 5.6 (2.3-6.7) 6.0 (2.5-7.6) Power Input (kW) 0.62 0.78 0.93 1.05 1.49 1.58 1.64 1.87 Rated EER/COP 4.03 3.85 3.76 3.80 3.35 3.16 3.41 3.20 Rated AEER/ACOP 3.88 3.73 3.68 3.73 3.31 3.12 3.35 3.16 Power Supply Single-phase, 50Hz, 230V Airflow m3/min 6.5-7.5-8.5 6.5-9-11.5 7-9-11.5 7.5-11.5-13 L/S 108-125-142 108-150-192 117-150-192 125-192-217 Sound Pressure Level (dB) 25-28-31 25-33-39 27-34-39 32-40-43 Dimensions Height (mm) Unit: 245, Panel: 10 Width (mm) Unit: 570, Panel: 625 Depth (mm) Unit: 570, Panel: 625 Weight (indoor) (kg) Unit: 15, Panel: 3 Refrigerant Piping Max. Length/Height (m) 20 / 12 30 / 30 Refer to page 20 for outdoor specifications. 3D i-See Sensor The 3D i-See Sensor works intuitively to detect the floor temperature and room occupancy; automatically switching to the optimal operating mode (including vane airflow direction) based on this information. With a total of eight sensors, which rotate a full 360° in three minute intervals, the 3D i-See Sensor is able to detect people’s positions within the room to provide direct or indirect airflow, including having different settings for each individual airflow / vane direction, as preferred. Find out more about this feature on page 19. Stylish, Slimline Design With an inconspicuous look that blends seamlessly into any room, the SLZ Series’ pure white colour and compact, linear design is ideal for discreet heating and cooling. A recipient of the Good Design Award, the SLZ Series fits into narrow ceiling spaces with a height of only 245mm. Low Noise Levels The patented 3D turbo fan with two-stage blade structure ensures low noise operation, for a quieter comfortable environment. Starting from a hushed 25dBA*, the SLZ Series offers whisper quiet operation. The SLZ Compact Cassette Series provides a smart solution to comfortable and efficient heating and cooling. Combining a stylish square design with the latest energy-saving technologies, it is designed to fit flush into ceilings – making it ideal in both homes and commercial spaces. Fresh Air Intake A duct opening is provided in the main body making it possible to bring fresh air in directly, where it can then be heated to provide clean, refreshing comfort. Customisable Airflow The SLZ Series offers improved airflow control with the ability to set six different airflow / vane settings (auto, or 5 x fixed directional settings). At the same time, the SLZ Series allows the ability to independently control each vane’s airflow pattern. The result? Fully customisable airflow management that helps eliminate uncomfortable draughts and/ or even air and temperature distribution across the entire space. Multiple Control Options The SLZ Series is available as either a Deluxe PAR Wired Wall Controller or Deluxe Wireless Infrared Handheld Controller option. At the same time, both options can be upgraded with optional Wi-Fi Control, allowing users to select a control solution that suits their requirements, and optimize energy efficiency with smart scheduling and room control. SLZ Series *SLZ-M25/35 indoor sound level on lowest fan speed. 13
Specifications: PLA Ceiling Cassette Series Refrigerant R32 Indoor Unit PLA-M71EA2 PLA-M100EA2 PLA-M125EA2 PLA-M140EA2 Outdoor Unit (Standard, Deluxe) SUZ-M71VAD PUZ-ZM71VHA2 PUZ-M100VKA PUZ-ZM100VKA2 PUZ-M125VKA PUZ-ZM125VKA2 PUZ-ZM140VKA2 Function Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating Cooling Heating Capacity (min.–max.) (kW) 7.1 (2.8-8.1) 8.0 (2.6-10.2) 7.1 (3.3-8.1) 8.0 (3.5-10.2) 10.0 (4.0-10.6) 11.2 (2.8-12.5) 10.0 (4.9-11.4) 11.2 (4.5-14.0) 12.0 (5.8-13.0) 14.0 (4.1-15.0) 12.5 (5.5-14.0) 14.0 (5.0-16.0) 13.5 (6.2-15.3) 16.0 (5.7-18.0) Power Input (kW) 1.87 2.17 1.78 2.03 2.88 2.98 2.43 2.94 3.46 3.85 3.55 3.58 3.93 4.48 Rated EER/COP 3.79 3.68 3.98 3.94 3.47 3.75 4.11 3.80 3.46 3.63 3.52 3.91 3.43 3.57 Rated AEER/ACOP 3.73 3.63 3.83 3.80 3.36 3.64 3.95 3.68 3.38 3.55 3.42 3.80 3.34 3.49 Power Supply 230V, Single-phase, 50Hz Airflow (Lo–Hi) m3/min 16-17-19-21 19-23-26-29 21-25-28-31 24-26-29-32 L/S 267-283-317-350 317-383-433-483 350-417-467-517 400-433-483-533 Indoor Sound Pressure Level (dB) 28-30-32-34 31 - 34 - 37 - 40 33 - 37 - 41 - 44 36-39-42-44 Dimensions Height (mm) Unit: 258, Panel: 40 Unit: 298, Panel: 40 Width (mm) Unit:840, Panel: 950 Unit: 840, Panel: 950 Depth (mm) Unit:840, Panel: 950 Unit: 840, Panel: 950 Indoor Unit Weight (kg) Unit: 21, Panel:5 Unit: 24, Panel: 5 Unit: 27, Panel: 5 Refrigerant Piping Max. Length/Height 30/30 50/30 55 / 30 75 / 30 55 / 30 75 / 30 Operation Range Outdoor Cooling (°C) -5(-15*2) ~ 52 -5(-15*2) ~ 46 -5(-15*2) ~ 52 -5(-15*2) ~ 46 -5(-15*) ~ 52 Heating (°C) -15 ~ 24 -20 ~ 21 -15 ~ 21 -20 ~ 21 -15 ~ 21 -20 ~ 21 Customisable Airflow The PLA Series offers improved airflow control with the ability to set six different airflow / vane settings (auto, or 5x fixed directional settings*1). At the same time, the PLA Series allows the ability to independently control each vane’s airflow pattern. The result? Fully customisable airflow management that helps eliminate uncomfortable draughts and/or even air and temperature distribution across the entire space. 3D i-See Sensor The 3D i-See Sensor works intuitively to detect the floor temperature and room occupancy; automatically switching to the optimal operating mode (including vane airflow direction) based on this information. With a total of eight sensors, which rotate a full 360° in three minute intervals, the 3D i-See Sensor is able to detect people’s positions within the room to provide direct or indirect airflow, including having different settings for each individual airflow / vane direction, as preferred. Find out more about this feature on page 19. Sleek, Compact Design The PLA Series features a sleek, square design with bevelled edges that provide a compact and modern finish. *2 With optional air protection guide. Refer to page 20 for outdoor specifications. The PLA Large Capacity Cassette Series with advanced airflow features and independent vane direction control, provides indoor comfort in a sleek unobtrusive design. Perfect for larger residential rooms or office spaces, the PLA Series provides consistent temperatures throughout the space you need to heat or cool. PLA Series Ceiling Cassette System Horizontal flow Vertical flow Set by remote controller Fixed *1 P Series Outdoor Unit connection only.
Wave Airflow Mode for Heating Advanced control of vanes, called Wave Airflow, provides even greater heat distribution by periodically moving vanes up and down to provide a consistent temperature throughout the room. Standard or Deluxe Outdoor Units The Standard Range of outdoor units, available in 10.0kW and 12.5kW, are the ideal economical solution for buildings or homes where extended pipe runs are not necessary. The Deluxe Outdoor Unit offers longer pipe runs, slightly lower Sound Pressure Levels and extended guaranteed heating down to -20°C. Wide Airflow PLA Series Cassettes utilise wide-angle outlets to distribute airflow to all corners of the room, ensuring the room is cooled/heated in an even manner. Both horizontal airflow and fan speed have been reduced by 20% compared to conventional models, contributing to increased comfort for occupants. Auto Fan Speed Mode The fan speed on PLA Series Cassettes is adjusted automatically, maintaining a comfortable environment at all times. At the start of operation, a high fan speed achieves quick heating/cooling of the room. Once the desired temperature is reached, the fan speed is reduced for stable, more efficient heating/cooling and greater comfort. Grille Options Wireless Grille options available in Pure White, and Wired Grille options available in Pure White and Black*3. Both the Wired Grille in Black and the Wired/Wireless Grille in White have the same sleek beveled design. Temperature gap with uneven temperature distribution Temperature gap is decreased, and room is warmed uniformly Swing mode Vertical flow Other Features • Stylish indoor unit vane covers (when unit is turned off) • Quiet operation with improved airflow path and powerful high-capacity flow fan • Built-in Drain Pump – maximum upward draining of 850mm • Deluxe Wireless Remote Controller option available • Duct flange for fresh-air intake • Branch duct *3 Black Wired Grille does not include 3D i-Sensor functionality. Optional 3D Harmony Upgrade Introducing the new PLA 3D Harmony Cassette range for the ultimate in comfort. With the addition of horizontal louvers, it delivers 360° airflow in conjunction with Mitsubishi Electric’s unique 3D i-See Sensor. The 3D Harmony Series prevents draughts and short cycling, while offering fully customisable airflow to suit any room layout and occupant position. Ideal for larger residential rooms and office spaces. Conventional model PLA-M**EA Optional Automatic Grille Lowering Function An Automatic Grille Lowering Function capable of stopping at eight different heights is available to simplify filter maintenance. • The packaged elevating (up/down) controller in the grille (PLP-6EAJE) is compatible with both PUZ Series or SUZ Series Systems. • The Wired PAR Remote Controller includes the Automatic Grille Lowering Function. This function is only available when the indoor unit is connected to the PUZ Series outdoor unit. Multiple Control Options The PLA Series Range is available as either a Deluxe PAR Wired Wall Controller or Deluxe Wireless Infrared Handheld Controller option. At the same time, both options can be upgraded with optional Wi-Fi Control, allowing users to select a control solution that suits their requirements, and optimize energy efficiency with smart scheduling and room control. Maximum 4m Automatic Elevation 15
The PCA Series high performance units are designed for style and efficiency. A stylish indoor unit design and airflow settings for both high and low-ceiling interiors expand installation possibilities. With four fan speed settings and auto air-speed adjustment, PCA Series units provide energy efficient comfort no matter the season. PCA Series Specifications: PCA Under-Ceiling Series Refrigerant R32 Indoor Unit PCA-M71KA2 PCA-M100KA2 PCA-M125KA2 PCA-M140KA2 Outdoor Unit PUZ-ZM71VHA2 PUZ-ZM100VKA2 PUZ-ZM125VKA2 PUZ-ZM140VKA2 Function Cooling Heating Cooling Heating Cooling Heating Cooling Heating Capacity (min.–max.) (kW) 7.1 (3.3-8.1) 8.0 (3.5-10.2) 10.0 (4.9-11.4) 11.2 (4.5-14.0) 12.5 (5.5-14.0) 14.0 (5.0-16.0) 13.5 (6.2-15.3) 16.0 (5.7-18.0) Power Input (kW) 1.82 2.15 2.55 3.28 3.77 4.22 4.15 4.72 Rated EER/COP 3.90 3.72 3.92 3.41 3.31 3.31 3.25 3.38 Rated AEER/ACOP 3.75 3.60 3.77 3.31 3.22 3.24 3.17 3.31 Power Supply V: Single-phase, 50Hz, 230V Airflow (Lo–Mid–Hi) m3/min 16-17-18-20 22-24-26-28 23-25-27-29 24-26-29-32 L/S 267-283-300-333 367-400-433-467 383-417-450-483 400-433-483-533 Sound Pressure Level (dB) 35-37-39-41 37-39-41-43 39-41-43-45 41-43-45-48 Dimensions Height (mm) 230 230 Width (mm) 1,280 1,600 Depth (mm) 680 680 Weight (kg) 32 37 38 40 Refrigerant Piping Max. Length/Height (m) 50 / 30 75 / 30 Refer to page 20 for outdoor specifications. Automatic Air-Speed Adjustment In addition to the conventional four fan speed settings, units are now equipped with an Automatic Air-Speed Adjustment Mode. This setting automatically adjusts the air-speed to conditions that match the room environment. At the start of heating/cooling operation, the airflow is set to high-speed to quickly heat/cool the room. When the room temperature reaches the desired setting, the airflow speed is decreased automatically for comfortable heating/cooling operation. Stylish Indoor Unit Design The stylish, sharp design of the PCA indoor unit blends in well with ceilings, for an unobtrusive installation. Optional Drain Pump The pumping height of the optional drain pump has been increased from 400mm to 600mm, expanding flexibility in choice of unit location during installation work. Strong Gentle Start of cooling/heating After room temperature is stabilised Under-Ceiling System Drain Pump Installation Drainage outlet can be 600mm above ceiling surface. Ceiling Surface 600mm
Specifications: PCA Under-Ceiling Series Refrigerant R32 Indoor Unit PCA-M50KA2 PCA-M60KA2 PCA-M71KA2 Outdoor Unit SUZ-M50VAD SUZ-M60VAD SUZ-M71VAD Function Cooling Heating Cooling Heating Cooling Heating Capacity (min.–max.) (kW) 5.0 (2.3-6.0) 6.0 (1.7-7.0) 6.0 (2.3-6.5) 7.0 (2.5-8.0) 7.1 (2.8-8.1) 8.0 (2.6-10.2) Power Input (kW) 1.28 1.65 1.60 1.72 1.98 2.24 Rated EER/COP 3.90 3.63 3.75 4.06 3.58 3.57 Rated AEER/ACOP 3.84 3.59 3.68 4.00 3.53 3.52 Power Supply V: Single-phase, 50Hz, 230V Airflow (Lo–Mid–Hi) m3/min 10-11-13-15 15-16-17-19 16-17-18-20 L/S 167-183-217-250 250-267-283-317 267-283-300-333 Sound Pressure Level (dB) 32-34-37-40 33-35-37-40 35-37-39-41 Dimensions Height (mm) 230 230 Width (mm) 960 1,280 Depth (mm) 680 680 Weight (kg) 26 32 Refrigerant Piping Max. Length/Height (m) 30 / 30 Refer to page 20 for outdoor specifications. Specifications: PCA-M71HA Under-Ceiling (Stainless Steel Indoor) Refrigerant R32 Indoor Unit PCA-M71HA2 Outdoor Unit PUZ-ZM71VHA2 Function Cooling Heating Capacity (min.–max.) (kW) 7.1 (3.3-8.1) 7.6 (3.5-10.2) Power Input (kW) 2.02 2.17 Rated EER/COP 3.51 3.50 Rated AEER/ACOP 3.39 3.39 Power Supply V: Single-phase, 50Hz, 230V Airflow (Lo–Mid–Hi) m3/min 16-18 L/S 267-300 Sound Pressure Level (dB) 37-39 Dimensions Height (mm) 280 Width (mm) 1136 Depth (mm) 650 Weight (kg) 42 Refrigerant Piping Max. Length/Height (m) 50 / 30 Refer to page 20 for outdoor specifications. Capacity High ceiling Standard ceiling Low ceiling PCA-M50 3.5m 2.7m 2.5m PCA-M60 3.5m 2.7m 2.5m PCA-M71 3.5m 2.7m 2.5m PCA-M100 4.2m 3.0m 2.6m PCA-M125 4.2m 3.0m 2.6m PCA-M140 4.2m 3.0m 2.6m Fresh Outside Air Intake Units are equipped with a knock-out hole that enables the induction of fresh outside air. Outside Air Intake Characteristics High/Low-Ceiling Modes All PCA Series units are equipped with High and LowCeiling Operation Modes, that make it possible to switch the airflow volume to match room height. The ability to choose the optimum airflow volume makes it possible to optimise the breezy sensation felt throughout the room. 50 0 -50 -100 -150 -200 -250 -300 Static pressure (Pa) Airflow volume (m³/min) PCA-M100–140KA2 PCA-M60/71KA2 PCA-M50KA2 0 1 2 3 4 17
Controllers Wall Mounted 7-Day Controller Optional Touch Panel Controller Optional Wall Mounted Simple Controller Optional Wi-Fi Zone Control Optional Wall Mounted Zone Controller The PAR Controller allows you to program up to eight stop/start patterns per day for up to seven days at a time. With an easy to read full dot LCD backlit screen, simple menu format and a variety of operation control functions, temperature monitoring and management is available at the touch of a button. The PAR-CT01 features a 3.5” HVGA Full Colour LCD touch panel screen, allowing 180 different colour patterns to be selected for control parameters or background. A simple operation panel is available to display only ON/OFF, set temperature and fan speed – ideal for hotels. Your company logo or image can be displayed on the screen and there is the ability to control two spaces and communicate with a smart phone or tablet device via Bluetooth. The PAC-YT52CRA Simple Controller provides simplified usage, with controls limited to ON/ OFF, Mode, Room Temperature, Fan Speed and additional Vane Control for cassettes and high walls. The backlit LCD screen provides easy operation in dark conditions, and the slim flat-back shape makes for a simple installation. With the addition of awardwinning Mitsubishi Electric Wi-Fi Control, the Zone Controller’s capabilities are expanded even further. Advanced temperature monitoring and management, customisable operation and expanded functionality are available in the palm of your hand with the Wi-Fi Control App. Now you can control and monitor ducted heat pump zones in real time from absolutely anywhere via your smartphone, tablet or online account; for the ultimate in total comfort. The PAC-ZC40~80 Zone Controller brings expanded functionality and interaction to realise even greater energy savings. With the ability to control up to eight zones*1, equipped with automatic unloading/ramping and three built-in sensor functions (temperature, occupancy, brightness), the Zone Controller brings intuitive, yet simple control to a whole new level. Temperature Sensor Sensing the return air of the indoor ducted unit is not always ideal. With an inbuilt thermostat (PAR-ZC01ME-E Wall Controller) the Zone Controller allows the actual usable space temperature to be measured, offering a more realistic and timely temperature measurement where it is needed most. Occupancy Sensor Incorporating a built-in Occupancy Sensor, the Zone Controller (via the PAR-ZC01ME-E Wall Controller) constantly monitors the usable area to detect vacancy. Once detected, the Zone Controller implements one of four user-defined energy-saving control options to reduce energy consumption; turn the unit ON/OFF, lower the fan speed, temperature offset, or turn user designated zones ON/OFF. Brightness Sensor Working in conjunction with the Occupancy Sensor, the Brightness Sensor can be set to maximise energy savings when it detects user defined “Light” or “Dark” conditions (lux values). Backlit LCD Touch Screen Featuring a backlit LCD screen for operation in dark conditions, and a user-defined LED indicator that lights up to indicate the current operation mode i.e. red for heating, blue for cooling, green for night setback – operation management is clear and simple. PAR-*MAA PAR-CT01 PAC-YT52CRA PAC-ZC40(H/L)-E *1 P Series Outdoor Unit connection only. 18
90° rotation 90° rotation 90° rotation 5 sec measurement 5 sec measurement 5 sec measurement 5 sec measurement *2 The sensor rotates 360° once every three minutes when there is significant temperature disparity and once every five minutes when a stable, even temperature has been reached. 360° Temperature Monitoring Equipped with eight, built-in intuitive sensors, the 3D i-See Sensor function is an infrared-based sensor that monitors floor-level temperatures throughout the room. The 3D i-See Sensor works to ensure even temperature distribution and maximise room comfort through 360° sensing that covers the whole floor space; giving a more accurate and even temperature reading and improving energy efficiency. 3D i-See Sensor Operation The 3D i-See Sensor rotates 360° every three minutes*2, taking five second measurements at each position to accurately determine floor-level temperatures on all sides of the room. The 3D i-See Sensor calculates the temperature by measuring the infrared rays emanating from the walls and floors. Highly Accurate Occupancy Direction Once a person is detected, the angle of the vane is automatically adjusted. Each vane can be independently set by the user to “Direct Airflow” or “Indirect Airflow”. Even Airflow – Airflow Only Where You Need It With Even Airflow Mode, the 3D i-See Sensor memorises people’s movements and furniture positions, efficiently distributing airflow only to where it is needed. Independent Vane Direction Setting With the ability to independently control each vane’s airflow pattern, PLA Series Cassettes are perfect for both residential and office/commercial environments. At the same time, the PLA Series allows the ability to independently control each vane’s airflow pattern. The result? Fully customisable airflow management that helps eliminate uncomfortable draughts and/or even air and temperature distribution across the entire space. Detect Number of People – No Occupancy Energy Savings The 3D i-See Sensor detects the number of people in the room and adjusts the system’s power accordingly. This makes automatic power-saving operation possible in places where the number of people changes frequently. When the area is continuously unoccupied, the system switches to a more enhanced power-saving mode i.e. In No Occupancy Energy Saving Mode, the unit automatically reduces power consumption by approximately 10% after ten minutes, and 20% after 60 minutes; or when in No Occupancy Auto-Off Mode, the unit turns off automatically (Auto-Off able to be set based on between 60-180 minutes no occupancy duration, as required). Advanced Feature 3D i-See Sensor – PLA and SLZ Cassette Series 8 Sensors Horizontal flow Vertical flow Set by remote controller Fixed Direct/Indirect setting : Direct : Indirect : Indirect : Direct Select: Outlet Angle 19
Outdoor Unit PUZ-M100VKA PUZ-M125VKA PUZ-M140VKA PUZ-ZM100VKA2 PUZ-ZM125VKA2 PUZ-ZM140VKA2 REFRIGERANT R32 External Finish Munsell 3.0Y 7.8 / 1.1 Power Supply Single-phase, 50Hz, 230V Compressor Output (kW) 1.5 2.5 Airflow (Cooling/Heating) m3/min(L/S) 79 (1317) 86 (1433) 120 (1996) 110 (1831) 120 (1996) Sound Pressure Level (Cooling/Heating) (dB)*1 52 / 54 54 / 56 53 / 54 49 / 51 50 / 52 Sound Power Level (Cooling/Heating) (dB) 71 / 72 72 / 74 71 / 72 69 / 69 70 / 70 70 / 71 Dimensions (H x W x D) (mm) 981x1050x330+40*2 1338x1050x330+40*2 1338x1050x330+40*2 Weight (kg) 76 84 99 114 Piping Length (Chargeless/ Max.) (m) 30 / 55 30 / 75 Protection Device Comp. surface thermo, HP Switch H.P switch, shell thermistor, over current detection, thermal protector Breaker Size (A) 32 40 32 40 Outdoor Unit PUZ-ZM160VKA PUZ-ZM180VKA PUZ-ZM200YKA PUZ-ZM250YKA REFRIGERANT R32 External Finish Munsell 3.0Y 7.8 / 1.1 Power Supply Single-phase, 50Hz, 230V Compressor Output (kW) 3.6 3.8 4.7 Airflow (Cooling/Heating) m3/min(L/S) 140 (2333) Sound Pressure Level (Cooling/Heating) (dB)*1 58/59 58/60 60/60 Sound Power Level (Cooling/Heating) (dB) 74/75 74/76 75/76 Dimensions (H x W x D) (mm) 1338x1050x330+40*2 Weight (kg) 115 136 139 Piping Length (Chargeless/ Max.) (m) 30 / 75 30 / 100 Protection Device H.P switch, shell thermistor, over current detection, thermal protector Breaker Size (A) 40 32 Outdoor Unit SUZ-M25VAD SUZ-M35VAD SUZ-M50VAD SUZ-M60VAD SUZ-M71VAD PUZ-ZM71VHA2 REFRIGERANT R32 External Finish Munsell 3.0Y 7.8 / 1.1 Power Supply Single-phase, 50Hz, 230V Compressor Output (kW) 0.47 0.66 0.90 0.90 1.20 1.30 Airflow (Cooling/Heating) m3/min(L/S) 36.3 (605) / 34.6 (577) 34.3 (572) / 32.7 (545) 45.8 (763) / 43.7(728) 50.1 (835) / 50.1 (835) 50.1 (835) / 50.1 (835) 55 (915) Sound Pressure Level (Cooling/Heating) (dB)*1 45 / 46 48 / 48 48 / 49 49 / 51 49 / 51 47 / 51 Sound Power Level (dB) 59 63 66 68 68 67 Dimensions (H x W x D) (mm) 550x800x285 550x800x285 714x800x285 880x840x330 880x840x330 943x950x330+25*2 Weight (kg) 30 35 41 54 55 70 Piping Length (Chargeless/ Max.) (m) 7 / 20 7 / 20 7 / 30 7 / 30 7 / 30 30 / 50 Breaker Size (A) 10 10 20 20 20 25 Outdoor Unit Specifications Note: Above specifications are for outdoor units only. *1 Sound pressure measurements were conducted in an anechoic chamber. The actual noise level depends on the distance from the unit and the acoustic environment. *2 Grille depth. 20
