Plasma Quad Connect Air Filtration Accessory

Optional Advanced Air Filtration System

We spend up to 80% of our time inside. As such, good indoor air quality is paramount to our well‑being. So how can home owners have the peace of mind they can breathe cleaner, healthier air all year round? 2

Introducing the Plasma Quad Connect Air Filtration System A new optional high wall accessory, featuring high-performance two stage plasma technology. This advanced filtration system works to clean away smells, dust, mould and other common household allergens, making it an ideal addition for asthma and allergy sufferers. MAC-100FT-E Dimensions (WxDxH): 500x168x56mm Weight: 1.6 kg Power Consumption: 4 W 3

4

Cleaner, Healthier Air with Two Stage Plasma Filter The Plasma Quad Connect is designed to work like an electrical curtain, using an advanced two-stage process which first makes plasma that breaks down air pollutants and then creates an electrical discharge that neutralises even microscopic particles in the air. In fact, it can even capture particles as small as PM2.5, that's 20 times smaller than the width of a human hair! Unseen to the human eye, these microscopic particles can easily penetrate deep into our lungs and even our bloodstream. The result? A more healthy and cleaner living environment that can be enjoyed year-round. Compatible Indoor Units Plasma Quad Technology works like an electrical curtain to catch and neutralise even microscopic particles in the air, to significantly improve indoor air quality. How it Works Wire Wire Dirty Air Clean Air Stage One Produces plasma to: Inhibit viruses and bacteria Break down allergens and mould Electrically (+) charge dust and microscopic particles PM2.5 Stage Two Creates a strong electrical (-) field to: Absorb dust and microscopic particles PM2.5 5

MICRO PARTICLES ALLERGENS VIRUSES PM2.5 Particles 99% neutralised in 300 minutes Cat fur and pollen 98% neutralised 99% neutralised in 175 minutes 25m³ test space. Life Science Research Laboratory, No. LSRL-21010E-E091 Mid Airflow Setting (1.0m/s) ITEA Report No. T1606028 25m³ test space. Test No. vrc.center, SMC No.R2-003 BACTERIA DUST & TICKS MOULDS 99% neutralised in 335 minutes 99.7% neutralised 99% neutralised in 160 minutes 30m³ test space. CHEARI (Beijing) Certification & Testing Co., Ltd. WK-21-50161 Mid Airflow Setting (1.0m/s). ITEA Report No. T1606028 25m³ test space. Life Science Research Laboratory, No. LSRL-51021E-E091 Highly Effective Filtration Independent test results confirm that the Plasma Quad Connect Filtration System achieves extremely high reduction results in the removal of allergen, mould, bacteria and virus particles in the room. This provides the ultimate peace of mind and ensures a healthier and cleaner living environment. 6

Available on New Installs and as an Optional Retrofit Designed to be installed directly above high wall units, the Plasma Quad Connect is an optional Advanced Air Filtration System, compatible with the following Mitsubishi Electric High Wall Systems*: • Standard GS Series • EcoCore AP Series – AP Mini, AP Classic and AP Plus • EcoCore Designer EF Series • Large Capacity AS90 • Large Capacity PKA-M • GE Series * Large Capacity PKA-RP High Walls, FH Series, FH HyperCore Series, FB Series, FB HyperCore Series and EcoCore GL Series. 7

For more information on Plasma Quad Connect please visit our website or call our Customer Service Team. www.mitsubishi-electric.co.nz | 0800 784 382 Wellington Head Office 1 Parliament Street PO Box 30772 Lower Hutt 5040 Phone 04 560 9147 Auckland Unit 1 / 4 Walls Road PO Box 12726 Penrose Auckland 1642 Phone 09 526 9347 Christchurch 44 Halwyn Drive PO Box 16904 Hornby Christchurch 8441 Phone 03 341 2837 Be sure to ask for Mitsubishi Electric. Other brands share the 3-diamond logo, however they are separate to the Mitsubishi Electric brand and cannot supply the models, features or guarantees outlined in this brochure. All models, features and specifications are subject to change and amendment at anytime – PRINTED JULY 2022
