Offering the Best System Solution for All Area Ventilation LGH-RVS Series – Sensible Heat Lossnay
Easy Installation Key Features Easy Drain Piping Light Chassis Being light in weight is one of the most important factors for installation. The light chassis of the LGH-RVS series can provide a huge advantage in terms of cost and safety in installation. Low Noise Operation and Energy Ef ciency The LGH-RVS series operates with low noise thanks to a specialized sirocco fan produced by Mitsubishi Electric. The fan balances airflow and static pressure to minimize the noise level. The series also incorporates high-efficiency motor to reduce energy consumption. Low noise and high efficiency are thus achieved with the LGH-RVS series! • Only one drain piping for both SA and EA. • 360-degree drain pipe connection. • Trap piping work is NOT required owing to an internal backflow stopper. Various Optional Parts The LGH-RVS series can connect with various optional parts. A CO2 sensor is one of the best solutions for optimized air volume control. The unit operates while optimizing air volume in accordance with the level of CO2 condensation in the room. Optimized ventilation can reduce the energy consumption of the air conditioner. A high-efficiency filter can be optionally installed in the unit as an easy solution for even better indoor air quality. 1 Drain Piping 190kg A 235kg B 270kg C Competitors 73kg *LGH-100RVS-E LGH-RVS Series CO2 sensor Silencer duct Filter
Supply air Return air Outdoor air Exhaust air CO2 Sensor The Sensible Heat Lossnay LGH-RVS Series, allows diverse solutions and options in response to customer needs. Three key features, namely “Easy Installation”, “Low Noise Operation”, and “High Energy Ef ciency”, provide energy savings and comfort! Automatic operation with CO2 sensor and PZ-62DR-E Fan speed automatically changes depending on CO2 concentration. A CO2 sensor connected directly to a Lossnay RVS unit optimizes the fan speed according to the level of CO2 detected. It improves total heat exchange efficiency and contributes to energy saving. CO2 levels are indicated by LED lights. PZ-70CSW-E (Wall mounted type) PZ-70CSB-E (Built-in type) Low CO2 density Fan speed 1 High CO2 density Fan speed 4 LGH-RVS Series CO2 sensor Silencer duct Supply air Return air Outdoor air Exhaust air CO2 Sensor The Sensible Heat Lossnay LGH-RVS Series, allows diverse solutions and options in response to customer needs. Three key features, namely “Easy Installation”, “Low Noise Operation”, and “High Energy Ef ciency”, provide energy savings and comfort! Automatic operation with CO2 sensor and PZ-62DR-E Fan speed automatically changes depending on CO2 concentration. A CO2 sensor connected directly to a Lossnay RVS unit optimizes the fan speed according to the level of CO2 detected. It improves total heat exchange efficiency and contributes to energy saving. CO2 levels are indicated by LED lights. PZ-70CSW-E (Wall mounted type) PZ-70CSB-E (Built-in type) Low CO2 density Fan speed 1 High CO2 density Fan speed 4 LGH-RVS Series CO2 sensor Silencer duct Unit: mm 400 350 300 250 200 150 100 50 0 95 90 85 80 75 70 65 60 55 0 200 100% Temp. exchange ef ciency Φ250 duct straight 123m Φ250 duct straight 110m Φ250 duct straight 60m 75% 50% 25% 400 600 800 Air ow 1,000 1,200 1,400 1,600 [m3/h] 0 50 100 150 200 250 300 350 400 [L/s] External static pressure [Pa] Exchange ef ciency [%] 400 350 300 250 200 150 100 50 0 95 90 85 80 75 70 65 60 55 0 200 400 600 800 Air ow 1,000 1,200 1,400 [m3/h] 0 50 100 150 200 250 300 350 [L/s] External static pressure [Pa] Exchange ef ciency [%] 100% Temp. exchange ef ciency Φ250 duct straight 175m Φ250 duct straight 100m Φ250 duct straight 60m 75% 50% 25% Inspection opening 450 ×450 or more Heat exchanger, Air lter, High-Ef ciency lter, Fan,drain pan maintenance space In case of xed ceiling (not grid ceiling), 150mm or more for drain maintenance Air supply fan Control box Air exhaust fan Alternative duct position Bypass damper plate Ceiling suspension xture (4-13 × 20 oval) Power supply opening High-Ef ciency lter(sold separately) position Heat exchanger (Lossnay core) Air lters Drain catch basin Back ow stopper Drain pipe(1/100 gradient) (Drain pipe can be set preferable direction) O.D Φ32 (VP25) Filter maintenance cover(Upper) Drain pan,cores,motors maintenance cover(Lower) Ceiling 1179 161 More than 600 150 to 250 1224 910 115 45 465 55 1185 82 82 Φ242 Φ258 20 1279 64 153 161 RA (return air) SA (supply air) EA (exhaust air outlet) OA (outside air intake) 165 Inspection opening 450 ×450 or more Heat exchanger, Air lter, High-Ef ciency lter, Fan,drain pan maintenance space In case of xed ceiling (not grid ceiling), 150mm or more for drain maintenance Air supply fan Control box Air exhaust fan Alternative duct position Bypass damper plate Ceiling suspension xture (4-13 × 20 oval) O.D Φ32 (VP25) High-Ef ciency lter(sold separately) position Heat exchanger (Lossnay core) Air lters Power supply opening Drain catch basin Back ow stopper Drain pipe (1/100 gradient) (Drain pipe can be set preferable direction) Drain pan,cores,motors maintenance cover (Lower) Ceiling Filter maintenance cover(Upper) 1179 161 More than 600 150 to 250 997 683 115 45 465 55 82 82 Φ242 Φ258 20 1051 64 153 161 RA (return air) SA (supply air) EA (exhaust air outlet) OA (outside air intake) 1185 165 Specifications LGH-100RVS-E Unit: mm Characteristic Curves Dimensions LGH-80RVS-E Characteristic Curves Dimensions Weight 73kg (89kg with maximum drain water) 220-240V/50Hz, 220V/60Hz 100% 75% 50% 25% Test condition 445 225 100 35 ISO 16494 Temp. exchange ef ciency is winter condition 1000 750 500 250 278 208 139 69 1.60 1.08 0.72 0.50 190 107 48 12 82.0 84.0 86.0 90.0 37.0 32.0 24.0 18.0 A-weighted sound pressure level @1.5m off from the center of the unit in an anechoic chamber 5 Tracer gas method @100% air ow (prEN308) 10MΩ or more AC 1000V 1 minute 4.20 6.1A @10ms, 3.6A@100ms Electrical power supply Fan speed Input power [W] Airflow [m3/h] [L/s] Specific fan power [W/(L/s)] External static pressure [Pa] Temp. exchange efficiency [%] Noise [dB] Exhaust air transfer ratio [%] Insulation resistance Dielectric strength Maximum current [A] Inrush current [A] Weight 63kg (77kg with maximum drain water) 220-240V/50Hz, 220V/60Hz 100% 75% 50% 25% Test condition 325 175 85 32 ISO 16494 Temp. exchange ef ciency is winter condition 800 600 400 200 222 167 111 56 1.46 1.05 0.77 0.58 170 96 43 11 82.0 84.0 86.0 90.0 36.0 30.0 25.0 18.0 A-weighted sound pressure level @1.5m off from the center of the unit in an anechoic chamber 5 Tracer gas method @100% air ow (prEN308) 10MΩ or more AC 1000V 1 minute 3.70 6.1A @10ms, 3.6A@100ms Electrical power supply Fan speed Input power [W] Airflow [m3/h] [L/s] Specific fan power [W/(L/s)] External static pressure [Pa] Temp. exchange efficiency [%] Noise [dB] Exhaust air transfer ratio [%] Insulation resistance Dielectric strength Maximum current [A] Inrush current [A] 2 Sensor The Sensible Heat Lossnay LGH-RVS Series, allows diverse solutions and options in response to customer needs. Three key features, namely “Easy Installation”, “Low Noise Operation”, and “High Energy Efficiency”, provide energy savings and comfort! Make Heat Recovery Ventilation Visible – with Optional Lossnay Wi-Fi Control Elevating air quality and maximising energy efficiencies has never been easier, because now the power is in your hands. See by how many degrees Lossnay is pre-warming or cooling your room in real time, helping you save on your power bill because less additional heating is required to get a room up to temperature. And in summer monitor by how many degrees Lossnay reduces your room temperature, using Automatic Free Cooling* Mode. View actual CO2 Levels and watch how the system automatically activates Boost Mode to maintain optimum air quality. The App will also proactively remind you when it is time to clean your filters to maximise both cost efficient operation and health benefits. Lossnay Wi-Fi Control truly is the smart evolution in fresh air ventilation. *In comparison to using a dedicated cooling device. The unit will continue to use a small amount of power to bring colder fresh air from outside.
Unit: mm 400 350 300 250 200 150 100 50 0 95 90 85 80 75 70 65 60 55 0 200 100% Temp. exchange ef ciency Φ250 duct straight 123m Φ250 duct straight 110m Φ250 duct straight 60m 75% 50% 25% 400 600 800 Air ow 1,000 1,200 1,400 1,600 [m3/h] 0 50 100 150 200 250 300 350 400 [L/s] External static pressure [Pa] Exchange ef ciency [%] 400 350 300 250 200 150 100 50 0 95 90 85 80 75 70 65 60 55 0 200 400 600 800 Air ow 1,000 1,200 1,400 [m3/h] 0 50 100 150 200 250 300 350 [L/s] External static pressure [Pa] Exchange ef ciency [%] 100% Temp. exchange ef ciency Φ250 duct straight 175m Φ250 duct straight 100m Φ250 duct straight 60m 75% 50% 25% Inspection opening 450 ×450 or more Heat exchanger, Air lter, High-Ef ciency lter, Fan,drain pan maintenance space In case of xed ceiling (not grid ceiling), 150mm or more for drain maintenance Air supply fan Control box Air exhaust fan Alternative duct position Bypass damper plate Ceiling suspension xture (4-13 × 20 oval) Power supply opening High-Ef ciency lter(sold separately) position Heat exchanger (Lossnay core) Air lters Drain catch basin Back ow stopper Drain pipe(1/100 gradient) (Drain pipe can be set preferable direction) O.D Φ32 (VP25) Filter maintenance cover(Upper) Drain pan,cores,motors maintenance cover(Lower) Ceiling 1179 161 More than 600 150 to 250 1224 910 115 45 465 55 1185 82 82 Φ242 Φ258 20 1279 64 153 161 RA (return air) SA (supply air) EA (exhaust air outlet) OA (outside air intake) 165 Inspection opening 450 ×450 or more Heat exchanger, Air lter, High-Ef ciency lter, Fan,drain pan maintenance space In case of xed ceiling (not grid ceiling), 150mm or more for drain maintenance Air supply fan Control box Air exhaust fan Alternative duct position Bypass damper plate Ceiling suspension xture (4-13 × 20 oval) O.D Φ32 (VP25) High-Ef ciency lter(sold separately) position Heat exchanger (Lossnay core) Air lters Power supply opening Drain catch basin Back ow stopper Drain pipe (1/100 gradient) (Drain pipe can be set preferable direction) Drain pan,cores,motors maintenance cover (Lower) Ceiling Filter maintenance cover(Upper) 1179 161 More than 600 150 to 250 997 683 115 45 465 55 82 82 Φ242 Φ258 20 1051 64 153 161 RA (return air) SA (supply air) EA (exhaust air outlet) OA (outside air intake) 1185 165 Specifications LGH-100RVS-E Unit: mm Characteristic Curves Dimensions LGH-80RVS-E Characteristic Curves Dimensions Weight 73kg (89kg with maximum drain water) 220-240V/50Hz, 220V/60Hz 100% 75% 50% 25% Test condition 445 225 100 35 ISO 16494 Temp. exchange ef ciency is winter condition 1000 750 500 250 278 208 139 69 1.60 1.08 0.72 0.50 190 107 48 12 82.0 84.0 86.0 90.0 37.0 32.0 24.0 18.0 A-weighted sound pressure level @1.5m off from the center of the unit in an anechoic chamber 5 Tracer gas method @100% air ow (prEN308) 10MΩ or more AC 1000V 1 minute 4.20 6.1A @10ms, 3.6A@100ms Electrical power supply Fan speed Input power [W] Airflow [m3/h] [L/s] Specific fan power [W/(L/s)] External static pressure [Pa] Temp. exchange efficiency [%] Noise [dB] Exhaust air transfer ratio [%] Insulation resistance Dielectric strength Maximum current [A] Inrush current [A] Weight 63kg (77kg with maximum drain water) 220-240V/50Hz, 220V/60Hz 100% 75% 50% 25% Test condition 325 175 85 32 ISO 16494 Temp. exchange ef ciency is winter condition 800 600 400 200 222 167 111 56 1.46 1.05 0.77 0.58 170 96 43 11 82.0 84.0 86.0 90.0 36.0 30.0 25.0 18.0 A-weighted sound pressure level @1.5m off from the center of the unit in an anechoic chamber 5 Tracer gas method @100% air ow (prEN308) 10MΩ or more AC 1000V 1 minute 3.70 6.1A @10ms, 3.6A@100ms Electrical power supply Fan speed Input power [W] Airflow [m3/h] [L/s] Specific fan power [W/(L/s)] External static pressure [Pa] Temp. exchange efficiency [%] Noise [dB] Exhaust air transfer ratio [%] Insulation resistance Dielectric strength Maximum current [A] Inrush current [A]
Unit: mm 400 350 300 250 200 150 100 50 0 95 90 85 80 75 70 65 60 55 0 100 200 300 400 500 600 700 800 900 Air ow 1,000 [m3/h] 0 50 100 150 200 250 [L/s] External static pressure [Pa] Exchange ef ciency [%] 100% Temp. exchange ef ciency Φ200 duct straight 130m Φ200 duct straight 60m Φ200 duct straight 40m 75% 50% 25% Inspection opening 450 × 450 or more In case of xed ceiling (not grid ceiling), 150mm or more for drain maintenance Heat exchanger, Air lter, High-Ef ciency lter, Fan,drain pan maintenance space Air supply fan Control box Air exhaust fan Alternative duct position Bypass damper plate Ceiling suspension xture (4-13 × 20 oval) O.D Φ32 (VP25) High-Ef ciency lter (sold separately) position Heat exchanger (Lossnay core) Air lters Power supply opening Drain catch basin Back ow stopper Drain pipe(1/100 gradient) (Drain pipe can be set preferable direction) Drain pan,cores,motors maintenance cover (Lower) Ceiling Filter maintenance cover (Upper) 969 120 More than 600 150 to 250 946 692 115 71 465 32 974 83 83 Φ208 Φ192 20 1001 64 153 120 RA (return air) SA (supply air) EA (exhaust air outlet) OA (outside air intake) 165 *When using a CO2 sensor. Upper and lower limits may be changed. LGH-50RVS-E Characteristic Curves Dimensions Controllers PZ-62DR-E PZ-43SMF-E CO2 indication Weight 55kg (67kg with maximum drain water) 220-240V/50Hz, 220V/60Hz 100% 75% 50% 25% Test condition 190 110 60 25 ISO 16494 Temp. exchange ef ciency is winter condition 500 375 250 125 139 104 69 35 1.37 1.06 0.86 0.72 150 84 38 9 87.0 89.0 91.0 93.0 33.0 27.0 22.0 18.0 A-weighted sound pressure level @1.5m off from the center of the unit in an anechoic chamber 5 Tracer gas method @100% air ow (prEN308) 10MΩ or more AC 1000V 1 minute 2.20 6.1A @10ms, 3.6A@100ms Electrical power supply Fan speed Input power [W] Airflow [m3/h] [L/s] Specific fan power [W/(L/s)] External static pressure [Pa] Temp. exchange efficiency [%] Noise [dB] Exhaust air transfer ratio [%] Insulation resistance Dielectric strength Maximum current [A] Inrush current [A] No Yes (Fan speed automatically changes from 25% to 100% depending on the CO2 concentration*) Control with a CO2 sensor Energy recovery/Bypass/Auto Energy recovery/Bypass/Auto Ventilation mode selection No Yes Night-purge No Yes Function setting from remote controller No Yes Bypass temp. free setting No Yes (Both supply and exhaust fan speeds can be set separately from 25% to 100% in 5% pitches) Multi-stage air ow control Yes Yes ON/OFF timer No Yes Auto-off timer No Yes Weekly timer No Yes Fan speed timer No Yes Operation restrictions (ON/OFF, ventilation mode, fan speed) No Yes Operation restrictions (fan speed skip setting) No Yes Screen contrast adjustment No (English only) Yes Language selection No Yes (available when using a CO2 sensor) CO2 concentration indication Yes Yes (maintenance interval can be changed) Filter cleaning sign Yes Yes (displays model name, serial number, contact information if they are input) Error indication No Yes Error history No Yes OA/RA/SA temp. display 2 of 4 fan speeds 4 fan speeds and Auto (Auto is available when using a CO2 sensor) Fan speed selection PZ-43SMF-E PZ-62DR-E Function
Filters Silencer Ducts Accessories Standard Filter Medium-efficiency Filter High-efficiency Filter A lineup of three types of filters offers optimum indoor air quality solutions! All filters are ISO and EN779:2012 certified, and can be easily installed in the units. Maintenance and exchanges can also be performed easily, simply by opening the maintenance panel. In facilities and applications requiring quiet operations, the silencer duct that reduces noise levels is the ideal solution. It contains glass wool and attenuates sound power by absorbing the noise from the airflow or operation of the unit. 1. Figures on the chart above are based on the comparison with a general steel duct of the same length. 2. The silencer is placed on just before the outlet during the measurement. 3. When the air ow rate differs, the insertion loss is also different from the chart above. 4. Figures on the chart above are at (No-weighted) values. Filter Lossnay Classification Filter material ISO 16890 (2016) EN779 (2012) Model name Included piece/set Applicable model Required set/unit 2 LGH-50RVS-E 1 PZ-S50RF-E 2 LGH-80RVS-E 1 PZ-S80RF-E 2 LGH-100RVS-E 1 PZ-S100RF-E Non-woven fabrics Coarse 50% G3 Filter Lossnay Classification Filter material ISO 16890 (2016) EN779 (2012) Model name Included piece/set Applicable model Required set/unit 2 LGH-50RVS-E 1 PZ-S50RFM-E 2 LGH-80RVS-E 1 PZ-S80RFM-E 2 LGH-100RVS-E 1 PZ-S100RFM-E Pleated lter ePM10 80% M6 Filter Lossnay Classification Filter material ISO 16890 (2016) EN779 (2012) Model name Included piece/set Applicable model Required set/unit 2 LGH-50RVS-E 1 PZ-S50RFH-E 2 LGH-80RVS-E 1 PZ-S80RFH-E 2 LGH-100RVS-E 1 PZ-S100RFH-E Pleated lter ePM10 90% ePM2.5 75% ePM1 65% F8 Model Direction Discharge Suction Discharge Suction Air flow 500 m3/h 650 m3/h 500 m3/h 650 m3/h 800 m3/h 1000 m3/h 800 m3/h 1000 m3/h 62.5Hz Attenuation of sound power level [dB] for center frequency 125Hz 250Hz 500Hz 1000Hz 2000Hz 4000Hz 8000Hz 0 1 4 7 13 18 16 9 0 1 3 8 12 17 14 6 0 1 4 8 11 17 14 8 0 0 3 7 10 11 12 5 0 2 4 12 22 21 14 13 0 1 4 12 22 20 14 13 0 3 5 12 18 14 11 4 0 2 4 12 17 16 13 8 PZ-200SS-E PZ-250SS-E S-175-1-CA695-A-NK-2105-IP www.MitsubishiElectric.com PUBLISHED DEC 2023 www.mitsubishi-electric.co.nz | 0800 784 382 Please note: When deciding on the best place to position the Lossnay Ventilation System, care needs to be taken to not have incoming air intake near or close to a wood burner flue.
