Adding fresh air to a single space has never been easier! Single Room Energy Recovery Ventilation Tiny Homes Retrofit High Density Granny Flats
Adding Energy Recovery Ventilation to Individual Spaces Has Never Been Easier The Mitsubishi Electric Lossnay VL100 Single Room Series makes adding energy recovery ventilation quick and fuss-free, with both wall-mounted and in-ceiling models to choose from. A well-ventilated room maintains air quality and helps control moisture build-up for a healthier, more comfortable environment year-round. Mitsubishi Electric’s patented Lossnay balanced pressure energy recovery system extracts stale air and replaces it with fresh filtered outdoor air, delivering comfort and efficiency all year round. The VL100 Series is ideal for small new-builds like tiny homes, granny flats, sleepouts and cabins, and a costeffective retrofit solution for existing spaces in homes like rumpus rooms, converted home offices, home gyms and hobby rooms. For apartments, townhouses and multi-level homes built without ventilation and prone to summer overheating, the VL100 Series is also a cost effective solution to bring filtered fresh air to individual rooms that need it most. Do you have space in your roof? • Ducted Ceiling Mount VL-100 • Wall Mount VL-100 YES NO Wall Mounted In-Ceiling How the Unique Lossnay Core Works Airflow shown in Winter Mode Exhaust Air As the stale Return Air is removed, the Lossnay Core ‘recovers’ the useful heat energy from it. The air is then exhausted outside along with the unwanted pollutants. Outdoor Air Fresh Outdoor Air is first filtered, then passed through the Lossnay Core. This allows it to be pre-warmed in winter (or pre-cooled in summer) using the energy recovered from the Return Air. Supply Air Supply Air then enters your house as fresh pre-warmed or pre-cooled air. Return Air The stale air extracted from your home is Return Air, which can contain high levels of CO2, odours and other pollutants. This Return Air stream also contains heat energy that Lossnay can recover, which is not the case with positive pressure ventilation systems. Exhaust Air Supply Air Outdoor Air Return Air
Shown for illustration purposes only. Who Can Benefit? Small New Builds Like Tiny Homes Tiny homes, granny flats, single room studios, converted sheds, cabins or container style offices commonly struggle with airflow and ongoing moisture build-up. With limited space and tight budgets, ducted mechanical ventilation isn’t practical, leaving rooms stuffy and damp. Renovated Spare Rooms In older homes, spare rooms are often renovated into home offices, gyms, rumpus rooms, or hobby spaces. But without accessible ceiling space for ducted systems, ventilation is an afterthought. Limited natural airflow means these rooms can feel stale and stuffy and suffer ongoing moisture issues. Rooms That Overheat in Summer Modern homes keep heat in and upstairs bedrooms pay the price. Without proper ventilation, summer heat builds fast and won’t budge. The problem is compounded when opening windows isn’t ideal due to noise, insects, or privacy and there’s no practical way to purge the heat. Rooms Without Ceiling Space Most existing homes weren’t built with mechanical ventilation in mind and many have no space to retrofit a ducted solution. This makes the VL100 Wall Mount a perfect standalone option to add fresh filtered air, simply and affordably. And because of the unique Lossnay Core, energy bills are minimised because incoming fresh air is pre-warmed with the outgoing stale air. Why the VL100 Wall Mount Works So Well ✓ Wall-mounted, so no ceiling or roof space for ducting is needed. ✓ Just two small 85-90mm holes in the exterior wall. ✓ Energy recovery maximises heating and cooling efficiencies. ✓ Helps retain warmth (or coolness) already in the room, saving on power bills. ✓ Constant fresh filtered air, without open windows. ✓ Great for rooms that are noisy, lack privacy, or get bugs when windows are left open. ✓ Helps tackle condensation and removes stale air. ✓ Perfect for detached rooms or small spaces prone to dampness.
Specifications Lossnay System Selection Guide PUBLISHED Sept 2025 www.mitsubishi-electric.co.nz | 0800 784 382 Please note: When deciding on the best place to position the Lossnay Ventilation System, care needs to be taken to not have incoming air intake near or close to a wood burner flue. Please Note: A ventilation system should not be purchased without first obtaining a quote by a qualified Mitsubishi Electric Authorised Installer. Selection Guide is based on the following criteria: • m2 Room/Area (at 0.5 Air Changes) with a ceiling height of 2.4m. • 10 year-old partially insulated building, single storey† with heat pump as the main heat source. • It is recommended to size your system based on Low-Medium Speed operation. † While the Selection Guide is based on single storey homes, Lossnay Ventilation Systems are not limited to this criteria. 150 Require to be secured 226 12 Front panel (Open position) Front panel louver (Horizontal position) Front panel louver (Vertical position) Front panel (Closed position) Edge of main unit 420 40 (Adjustable) 108 119 95 25 15 95.5 Pitch 20x10=200 265 13.5 238.5 183min from nearest obstruction 233min 75 87 267.5 554 22 292 75 (Adjust able) (Adjust able) Mounting holes 36× 6 530 360min from nearest obstruction 200 (min) 350 (max) 360min 620 Air exhaust hole 85 to 90 wall hole Outer dia 79×2 Shutter knob (Open position) Wall thickness 50 to 550 Shutter knob (Closed position) Fresh air supply 90 140 200 5° 106 22 17 97 25 Power cord hole Indoor air exhaust Mounting plate Air intake hole 85 to 90 wall hole Outer dia 75×2 Require to be secured 620 Unit (mm) Single Room VL100 Wall Mount | VL-100EU5-E 230 ＳＡ ＲＡ (Return Air) (Supply Air) (Unit : mm) 13 147.5 370 440 33 Ceiling suspension fixture (included) Mounting position (4 point hanging) Power and connection cable pullout area 26.5 69.5 ø105 ø98 9 204 131 386 106 412 370 300 436 412 370 300 220 455 ＰＵＳＨ ＰＵＳＨ (For body mounting) Mounting hole 8 locations × 5 × 7 Mounting hole 8 locations × 5 × 7 Mounting hole 2 locations × 5 × 9 (For duct connection plate mounting) (For ceiling suspension fixture mounting) ＥＡ (Exhaust Air) ＯＡ (Outside Air) Single Room VL100 Ducted Ceiling Mount | VL-100ZSKRT-E Type Supply Voltage (V) Power Line Frequency (Hz) Fan Speed Air Volume (m3/h) Air Volume (l/s) Power Consumption (W) Temp. Exchange Efficiency (%) Noise (dB) Weight (kg) VL-100EU5-E Wall Mount 230 50 HI 105 29.1 31 73 37 7.5 LO 60 16.6 15 80 25 VL-100ZSKRT-E Ducted Ceiling Mount 230 50 HI 78 21.7 32 52 40 6.0 LO 42 11.7 15 64 25.5 Fan Speed Model Type HRV or ERV Extract Damp Air LOW MED MED/HIGH HIGH m2 m2 m2 m2 VL-100EU5-E Wall Mount ERV No 50 88 VL-100ZSKRT-E Ducted Ceiling Mount ERV No 35 65 Want to Know More? View individual Lossnay Product Brochures for more information.
