Lossnay VL100 Single Room Energy Recovery Ventilation

Balanced Pressure Room Ventilation | Made in Japan | Designed for New Zealand Conditions VL100 Single Room Series – Energy Recovery Ventilation

Single Room Energy Recovery Ventilation A Mitsubishi Electric Lossnay Single Room Ventilation System is designed to provide cost effective energy recovery ventilation to one specific area in the home. The Lossnay VL100 Range includes a ducted model that is the perfect unobtrusive inceiling solution. For applications without adequate roof space, there is a ductless unit purpose-built to accommodate a simple back-to-back wall mount installation. Balanced Pressure Energy Recovery Ventilation The balanced pressure ventilation system captures and filters fresh outdoor air (as opposed to stale attic air) to replace indoor stale air for an all-round healthier, drier and warmer room. This system is ideal for modern homes that are of more airtight construction. The Lossnay Core The Lossnay Core recovers energy from the extracted stale air, to pre-warm or pre-cool the incoming air. As a result, an existing heating appliance in the room does not have to work as hard to reach desired temperatures, maximising energy efficiency and reducing your energy bill. The Benefit of Fresh Air Stale air with higher levels of CO2 is a common problem not only in schools and offices but also in homes where structures are becoming more and more airtight due to more stringent building regulations. High levels of CO2 can affect concentration and learning as well as overall wellbeing and productivity. Furthermore, the lack of natural ventilation in airtight spaces can lead to the build-up of moisture-laden stale air. This is the perfect breeding ground for mould that can trigger allergy or respiratory problems. The option of leaving doors and windows open to allow fresh air to enter is not always desirable or practical, with potential security risks and greater exposure to outdoor noise. This is where a fresh air ventilation system like Lossnay can make a real difference. Key Lossnay Ventilation Benefits Brings fresh filtered air in Removes stale air Reduces moisture build-up Improves air quality for better health and wellbeing Efficient energy recovery that prewarms or pre-cools incoming air

Single Room VL100 Wall Mount Fresh Air Energy Recovery Ventilation This wall mounted unit provides an effective balanced pressure ventilation solution for a specific area up to 90m2*. Lossnay recovers energy from the air being transferred to pre-warm (or pre-cool) the fresh air drawn into the room. As a result, moisture build-up is minimised and a warmer, drier and healthier indoor environment can be maintained all year round. Because this model is ductless in design, it is ideal for applications where there is no roof space to accommodate the heat exchanger and duct work. Single Room VL100 Ducted Ceiling Mount Fresh Air Energy Recovery Ventilation This ducted model is specifically designed to provide energy efficient ventilation to ensure an individual area up to 65m2* has a constant supply of filtered fresh air whilst minimising moisture build-up. Furthermore, incoming air is pre-warmed (or pre-cooled) so your existing heating appliance does not need to work as hard to reach desired temperatures. Key Specifications of the VL100 Wall Mount • Up to 80% heat exchange efficiency • Simple installation by drilling two 75mm diameter installation holes • Low noise operation from 25dB on low fan speed • Easy to clean filters • Ideal for residential or small commercial applications where there is no roof space Key Specifications of the VL100 Ducted • Up to 64% heat exchange efficiency • Low height 204mm • 100mm duct diameter • Lightweight and compact • Low noise operation from 25dB on low fan speed • Remote Controller • Filter replacement notification • Air intake can be installed away from the unit in the most convenient location • Ideal for residential or small commercial applications with ceiling void or roof space Wall mounted remote control for ducted model. NEW PRODUCT * Based on 0.5ac/h In summer a traditional ventilator captures fresh air at the hot outside temperature. Lossnay Ventilation lowers the outside air temperature before bringing the fresh, filtered air inside. Energy Recovery Ventilation Works All Year Round TRADITIONAL VENTILATION LOSSNAY VENTILATION VENTILATOR HEATING 22°C EXHAUST AIR 22°C INSIDE TEMP 22°C INSIDE TEMP 0°C OUTSIDE TEMP 0°C OUTSIDE TEMP 0°C SUPPLY AIR HEATING 4.4°C EXHAUST AIR 22°C RETURN AIR 17.6°C SUPPLY AIR LOSSNAY In winter a traditional ventilator captures fresh air at the cold outside temperature. Lossnay Ventilation preheats the outside air before bringing the fresh, filtered air inside. Based on using a VL-100EU5-E at low fan speed. Based on using a VL-100EU5-E at low fan speed. TRADITIONAL VENTILATION LOSSNAY VENTILATION VENTILATOR COOLING 22°C EXHAUST AIR 22°C INSIDE TEMP 22°C INSIDE TEMP 32°C OUTSIDE TEMP 32°C OUTSIDE TEMP 32°C SUPPLY AIR COOLING 30°C EXHAUST AIR 22°C RETURN AIR 24°C SUPPLY AIR LOSSNAY

Lossnay Technical Specifications Type Supply Voltage (V) Power Line Frequency (Hz) Fan Speed Air Volume (m3/h) Air Volume (l/s) Power Consumption (W) Temp. Exchange Efficiency (%) Noise (dB) Weight (kg) VL-100EU5-E Back-to-Back Wall Mount 230 50 HI 105 29.1 31 73 37 7.5 LO 60 16.6 15 80 25 VL-100ZSKRT-E Ducted Ceiling Mount 230 50 HI 78 21.7 32 52 40 6.0 LO 42 11.7 15 64 25.5 150 Require to be secured 226 12 Front panel (Open position) Front panel louver (Horizontal position) Front panel louver (Vertical position) Front panel (Closed position) Edge of main unit 420 40 (Adjustable) 108 119 95 25 15 95.5 Pitch 20x10=200 265 13.5 238.5 183min from nearest obstruction 233min 75 87 267.5 554 22 292 75 (Adjust able) (Adjust able) Mounting holes 36× 6 530 360min from nearest obstruction 200 (min) 350 (max) 360min 620 Air exhaust hole 85 to 90 wall hole Outer dia 79×2 Shutter knob (Open position) Wall thickness 50 to 550 Shutter knob (Closed position) Fresh air supply 90 140 200 5° 106 22 17 97 25 Power cord hole Indoor air exhaust Mounting plate Air intake hole 85 to 90 wall hole Outer dia 75×2 Require to be secured 620 Unit (mm) 230 SA RA (Return Air) (Supply Air) (Unit : mm) 13 147.5 370 440 33 Ceiling suspension fixture (included) Mounting position (4 point hanging) Power and connection cable pullout area 26.5 69.5 ø105 ø98 9 204 131 386 106 412 370 300 436 412 370 300 220 455 PUSH PUSH (For body mounting) Mounting hole 8 locations × 5 × 7 Mounting hole 8 locations × 5 × 7 Mounting hole 2 locations × 5 × 9 (For duct connection plate mounting) (For ceiling suspension fixture mounting) EA (Exhaust Air) OA (Outside Air) Single Room VL100 Wall Mount | VL-100EU5-E Single Room VL100 Ducted | VL-100ZSKRT-E PUBLISHED NOV 2023 www.mitsubishi-electric.co.nz | 0800 784 382 Please note: When deciding on the best place to position the Lossnay Ventilation System, care needs to be taken to not have incoming air intake near or close to a wood burner flue.
