Lossnay Vertical Heat Recovery Ventilation

Balanced Pressure Whole Home Ventilation | Made in Japan | Designed for New Zealand Conditions Vertical Heat Recovery Ventilation

Introducing – the Vertical Lossnay Range Mitsubishi Electric has launched the next generation of Whole Home Fresh Air Heat Recovery Ventilation that does not require installation in the attic. While exposed ceilings are great from an architectural aesthetics perspective, it limits the ability to install a traditional roof based ventilation system. Designed for Flexibility and Convenience The Vertical Lossnay Range is designed specifically for the New Zealand housing market and makes energy efficient, super-quiet ventilation accessible to even more homes. Because of the slimline, vertical upright design, the Lossnay Ventilation System is not limited to an in-roof installation. With its small upright footprint, it can be placed in the garage or a cupboard in the kitchen. Now whole home ventilation can be installed and integrated in the overall building design without limitations. Slimline to Fit in a Cupboard The vertical upright design of the Lossnay Ventilation System is not limited to an inroof installation. Now whole home ventilation can be integrated into the overall building design without limitations. Automatic Free Cooling* Mode – Summer Bypass Using the on-board temperature sensors, the Vertical Lossnay automatically enters Bypass Mode when it detects the outside air is cooler than the desired set temperature inside the home. As a result, cooler fresh air is introduced and stale air is extracted, both bypassing the Lossnay Core. This is ideal for cooling down a dwelling that may have overheated during the day once the outside temperature has dropped in the evening. Easy to Use Control A built-in LCD controller allows for easy control and commissioning of the unit. This interface displays all functionality and temperature settings of the system. Make Heat Recovery Ventilation Visible – with Advanced Lossnay Wi-Fi Control Elevating air quality and maximising energy efficiencies has never been easier, because now the power is in your hands. See by how many degrees*2 Lossnay is pre-warming or cooling your home in real time, helping you save on your power bill because less additional heating is required to get a room up to temperature. And in summer, monitor by how many degrees Lossnay reduces the average temperature in your home, using Automatic Free Cooling* Mode. The app will also proactively remind you when it is time to clean your filters to maximise both cost efficient operation and health benefits. Lossnay Wi-Fi Control truly is the smart evolution in fresh air ventilation. VL-250 Dimensions (WxDxH): 595 x 356 x 565mm VL-350 Dimensions (WxDxH): 658 x 432 x 623mm VL-500 Dimensions (WxDxH): 725 x 556 x 632mm Available in Left and Right Hand Options *2 The outside ‘Fresh Air’ and the inside ‘Avg Temp’ air temperatures are measured by the built-in sensors that are centrally located in the main Lossnay Ventilation unit. * In comparison to using a dedicated cooling device. The unit will continue to use a small amount of power to bring colder fresh air from outside. Note: All images are for illustrative purposes only.

Fresh Air Heat Recovery Ventilation Lossnay is Designed for Today’s Modern Homes The word “Lossnay” originated from the Japanese word “Loss-Nai”, meaning “No Loss”. Lossnay is a patented Balanced Pressure Heat Recovery Ventilation System ideal for more airtight homes built to the current New Zealand Building Code. Using Lossnay Ventilation Systems can achieve compliance with the Ventilation Standard NZS4303:1990 that specifically requires ventilation systems to draw fresh air from the outside and not the roof space to achieve acceptable indoor air quality. Ventilation and Airtight Building Design Creating a healthy living environment is important when renovating or building a new home – you will want the perfect indoor climate year-round. In addition to efficient heating and cooling, this should include the optimum amount of fresh air. Current building regulations now demand homes to be built more airtight as they are subjected to higher insulation standards. The option of leaving doors or windows open to allow more fresh air to enter is often not the solution from an outdoor noise or security perspective. Ventilation, Condensation and Moisture Management The lack of natural ventilation due to airtight spaces can lead to the build-up of moisture-laden stale air within the home and creates the perfect breeding ground for mould that can trigger allergy or respiratory problems. Mould and dampness can compromise both building materials as well as furnishings inside the home. Common places for mould to grow include window sills, curtains and carpets. Advanced Filtration for Better Health and Wellbeing The quality of indoor air is an important factor for health and wellbeing and the new Vertical Lossnay Range ensures there is a constant flow of fresh air into our homes, and that potentially harmful pollutants and chemicals are being removed at the same time. The new residential range comes with optional NOx (nitrogen oxide) and Particulate Matter Filtration, with a unique third filter pocket which can be used for additional filtration of NOx emissions. This means that homes in even the most polluted environments can be supplied with clean, healthy air. Furthermore, the inbuilt filters are easily accessible for regular maintenance. Energy Efficient Operation Ventilating our indoor spaces is more important than ever, but we also need to be as energy efficient as possible. The new Vertical Lossnay will deliver filtered indoor air whilst recovering energy to minimise waste. In fact, Lossnay’s unique heat recovery technology recovers up to 85% of the heat energy from the outgoing stale air which is then used to pre-warm incoming fresh air.

Improved Air Quality By drawing in fresh outdoor air, indoor air quality is improved as high levels of CO2, odours and other pollutants are removed from your home. Fresh Air Without Open Windows Lossnay allows you to have a well-ventilated home without the need to open windows. This improves the safety of your home and family and means outdoor noise is minimised. Retains Heat Lossnay’s unique Heat Recovery Technology recovers up to 85% of the heat energy in outgoing air which is then used to pre-warm or cool the incoming fresh air. Balanced Pressure, No Draughts Lossnay is specifically designed for more airtight homes built to the current New Zealand Building Code; delivering the optimum amount of fresh air without creating draughts and minimising indoor temperature fluctuations. Whisper Quiet Operation From an ultra quiet 15dB*, the Vertical Lossnay is the ideal solution for residential homes and apartments where comfort is key. Energy Efficient Boasting an A+ efficiency rating, incoming fresh air is pre-warmed so your heating system isn’t required to work as hard to reach a desired temperature. This is highly energy efficient, and can help reduce heating bills. Creates a Healthier Home Filtered fresh air improves air quality for allergy and asthma sufferers. Assists with Moisture and Condensation Control Effectively reduces moisture in your home by directly removing stale air that causes condensation. Easy Control At Your Finger Tips An intuitive controller with easy-to-read LCD display comes mounted as standard. Fan speed, night set back and 24-hour and weekly timers can easily be customised and programmed with multiple stop and start patterns per day. Easy To Clean The standard filters can be removed for regular cleaning to keep the unit in optimal working condition. The Lossnay Difference Ventilating your home is vital as it maintains air quality and reduces moisture, creating a healthier and more comfortable environment. The Mitsubishi Electric Lossnay System is a patented heat recovery ventilation solution that uses fresh air (not attic air) to ventilate your home. The system works by extracting stale air from inside your house and replacing it with allergen-reduced fresh air from outside. Furthermore, Lossnay also recovers heat energy from the out going stale air to pre-warm (or pre-cool) the fresh air being drawn into your home. *On fan speed 1. Sound pressure level at 3m.

Why Outside Air, Not Attic Air? Not all air is created equal. Lossnay only draws fresh air from the outside – it does not draw air from the attic. The absence of significant air movement common in attics means the air is likely to be stale. In addition, build-up of dust, dirt and other contaminants such as mould, insect and rodent droppings makes this air much harder to filter before it is distributed through your home. This is why the Balanced Pressure Lossnay System specifically utilises direct fresh air instead. The Lossnay Core The Balanced Pressure Lossnay Heat Recovery Ventilation System removes stale, dirty air and draws in fresh air from outside. Lossnay also recovers heat energy from the air being transferred to pre-warm (or pre-cool) the fresh air being drawn into your home. Lossnay is ideal for small to large sized homes between 52m2 and 400m2. The stale air extracted from your home is Return Air (RA). Return Air can contain high levels of CO2, odours and other pollutants. This Return Air stream also contains heat energy that Lossnay can recover, which is not the case with positive pressure ventilation systems. As the stale Return Air is removed, the Lossnay Core ‘recovers’ the useful heat energy from it. The air is then exhausted (EA) outside along with the unwanted pollutants. Outdoor Air (OA) is introduced to provide fresh air. It is first filtered, then passed through the Lossnay Core. This allows it be pre-heated in winter (or pre-cooled in summer) using the energy recovered from the Return Air. Supply Air (SA) then enters your house as fresh pre-heated or pre-cooled air. EA Exhaust Air SA Supply Air OA Outdoor Air RA Return Air EA RA OA SA

202 202 181 88 32 595 φ122 224 219 86 318 269 115 10 356 20 179 20 242 51 565 14 Unit (mm) Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Pipe guide (SA) Pipe Return Air Outdoor Air Supply Air guide (RA) Pipe guide (OA) Filter cover (RA) Filter cover (OA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Wall mou 1 Accessories Wall bracket: RA: Return Air SA: Supply Air EA: Exhaust Air OA: Outdoor Air VL-250CZPVU-L-E – Left Mounted Controller Pipe guide (EA) Exhaust Air Specifications Model VL-250CZPVU-L/R-E Electrical Power Supply 220–240V / 50Hz Ventilation Mode Heat Recovery Mode Heat Exchanger Type Sensible Heat Exchanger Fan Speed FS4 (100%) FS3 (70%) FS2 (50%) FS1 (30%) Running Current A 0.76 0.35 0.20 0.12 Input Power W 106 44 23 11 Air Flow m3/h 250 175 125 75 L/s 69 49 35 21 External Static Pressure Pa 150 74 38 14 Temperature Exchange Efficiency % 85 87 88 90 Sound Pressure Level at 3m dB 31 22 16 15> Energy Efficiency Class (ErP) A+ Weight kg 26 Dimensions (HxWxD) mm 565x595x356 0.0 20.0 40.0 60.0 80.0 100.0 55 60 65 70 75 80 85 90 95 0 50 100 150 200 250 300 350 400 0 100 200 300 400 Exchange efficiency (%) 100% 70% 50% 30% 45m 35m 25m Static Pressure (Pa) Air volume ø125mm dia straight pipe length ( m3/h ) ( L/s ) Temperature exchange efficiency Performance Characteristic Curve VL-250CZPVU-L-E 202 202 181 88 32 595 φ122 224 219 86 318 269 115 10 356 20 179 20 242 51 565 14 Unit (mm) Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Pipe guide (SA) Pipe Return Air Outdoor Air Supply Air guide (RA) Pipe guide (OA) Filter cover (RA) Filter cover (OA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Wall mo 1 Accessories Wall bracket: RA: Return Air SA: Supply Air EA: Exhaust Air OA: Outdoor Air VL-250CZPVU-L-E – Left Mounted Controller Pipe guide (EA) Exhaust Air 202 202 181 88 32 595 φ122 224 219 86 318 269 115 10 356 20 40 40 228 423 30 179 179 179 681 20 242 51 565 14 Unit (mm) Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Pipe guide (SA) Pipe Return Air Outdoor Air Supply Air guide (RA) Pipe guide (OA) Filter cover (RA) Filter cover (OA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Wall mount hook center 1 Accessories Wall bracket: RA: Return Air SA: Supply Air EA: Exhaust Air OA: Outdoor Air VL-250CZPVU-L-E – Left Mounted Controller Pipe guide (EA) Exhaust Air 202 202 181 88 32 595 φ122 224 219 86 318 269 115 10 356 20 179 20 242 51 565 14 Unit (mm) Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Pipe guide (SA) Pipe Return Air Outdoor Air Supply Air guide (RA) Pipe guide (OA) Filter cover (RA) Filter cover (OA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Wall mo 1 Accessories Wall bracket: RA: Return Air SA: Supply Air EA: Exhaust Air OA: Outdoor Air VL-250CZPVU-L-E – Left Mounted Controller Pipe guide (EA) Exhaust Air 202 202 181 88 20 φ122 51 565 14 242 595 32 681 219 224 280 309 126 83 10 356 20 40 40 30 179 179 179 228 423 Unit (mm) Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Pipe Exhaust Air guide (EA) Pipe Outdoor Air guide (OA) Pipe Supply Air guide (SA) Pipe Return Air guide (RA) Filter cover (OA) Filter cover (RA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Wall mount hook center VL-250CZPVU-R-E – Right Mounted Controller 181 88 20 51 565 14 681 280 10 356 20 40 40 30 179 179 179 228 423 Unit (mm) Drain pipe (SA) φ22 PCB Under Cover Pipe Supply Air guide (SA) Pipe Return Air guide (RA) Filter cover (RA) Filter cover (SA) Wall bracket (accessory) Wall mount hook center d Controller 202 202 181 88 20 φ122 51 565 14 242 595 32 681 219 224 280 309 126 83 10 356 20 40 40 30 179 179 179 228 423 Unit (mm) Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Pipe Exhaust Air guide (EA) Pipe Outdoor Air guide (OA) Pipe Supply Air guide (SA) Pipe Return Air guide (RA) Filter cover (OA) Filter cover (RA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Wall mount hook center VL-250CZPVU-R-E – Right Mounted Controller VL-250CZPVU-L-E VL-250CZPVU-R-E Left sided Outdoor Air (OA) and Exhaust Air (EA) connections Right sided Outdoor Air (OA) and Exhaust Air (EA) connections VL-250CZPVU-L/R-E Performance Characteristic Curve Top View Top View Front View Front View Rear View Rear View Bottom View Bottom View Side View Side View 202 202 181 88 20 φ122 51 565 14 242 595 32 681 219 224 280 309 126 83 10 356 20 40 40 30 179 179 179 228 423 Unit (mm) Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Pipe Exhaust Air guide (EA) Pipe Outdoor Air guide (OA) Pipe Supply Air guide (SA) Pipe Return Air guide (RA) Filter cover (OA) Filter cover (RA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Wall mount hook center VL-250CZPVU-R-E – Right Mounted Controller Please note: When deciding on the best place to position the Lossnay Ventilation System, care needs to be taken to not have incoming air intake near or close to a wood burner flue.

658 623 84 55 95 322 372 121 209 111 200 192 222 221 192 15 30 10 20 242 242 4 242 φ145 20 432 Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Filter cover (RA) Filter cover (OA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Wall moun Unit (mm) Pipe guide (EA) Exhaust Air Outdoor Air Pipe guide (OA) Pipe Return Air guide (RA) Pipe guide (SA) Supply Air VL-350CZPVU-L-E – Left Mounted Controller Static Pressure (Pa) 0.0 20.0 40.0 60.0 80.0 100.0 120.0 60 65 70 75 80 85 90 95 0 50 100 150 200 250 300 350 0 100 200 300 400 500 100% 70% 50% 30% 55m 40m 25m ø150mm dia straight pipe length ( m3/h ) ( L/s ) Exchange efficiency (%) Air volume Temperature exchange efficiency Performance Characteristic Curve VL-350CZPVU-L-E Model VL-350CZPVU-L/R-E Electrical Power Supply 220–240V / 50Hz Ventilation Mode Heat Recovery Mode Heat Exchanger Type Sensible Heat Exchanger Fan Speed FS4 (100%) FS3 (70%) FS2 (50%) FS1 (30%) Running Current A 1.08 0.52 0.31 0.18 Input Power W 155 71 37 19 Air Flow m3/h 320 224 160 96 L/s 89 62 44 27 External Static Pressure Pa 150 74 38 14 Temperature Exchange Efficiency % 85 87 88 90 Sound Pressure Level at 3m dB 35 26 19 15> Energy Efficiency Class (ERP) A+ Weight kg 32 Dimensions (HxWxD) mm 623x658x432 VL-350CZPVU-L-E VL-350CZPVU-R-E Left sided Outdoor Air (OA) and Exhaust Air (EA) connections Right sided Outdoor Air (OA) and Exhaust Air (EA) connections VL-350CZPVU-L/R-E Performance Characteristic Curve 658 623 84 55 95 322 372 121 209 111 200 192 222 221 192 15 30 10 20 242 242 242 φ145 20 432 Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Filter cover (RA) Filter cover (OA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Wall mo Unit (mm) Pipe guide (EA) Exhaust Air Outdoor Air Pipe guide (OA) Pipe Return Air guide (RA) Pipe guide (SA) Supply Air VL-350CZPVU-L-E – Left Mounted Controller 658 623 84 55 95 322 372 121 209 111 200 200 200 192 222 221 192 736 15 30 10 20 242 242 246 40 40 242 φ145 20 432 460 Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Filter cover (RA) Filter cover (OA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Wall mount hook center Unit (mm) Pipe guide (EA) Exhaust Air Outdoor Air Pipe guide (OA) Pipe Return Air guide (RA) Pipe guide (SA) Supply Air VL-350CZPVU-L-E – Left Mounted Controller 658 623 84 55 95 322 372 121 209 111 200 192 222 221 192 15 30 10 20 242 242 242 φ145 20 432 Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Filter cover (RA) Filter cover (OA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Wall mou Unit (mm) Pipe guide (EA) Exhaust Air Outdoor Air Pipe guide (OA) Pipe Return Air guide (RA) Pipe guide (SA) Supply Air VL-350CZPVU-L-E – Left Mounted Controller Top View Front View Rear View Bottom View Side View 20 192 222 20 222 192 209 112 55 84 623 15 242 658 242 242 350 377 149 106 10 432 200 200 200 40 246 460 40 736 30 φ145 Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Filter cover (OA) Filter cover (RA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Unit (mm) Wall mount hook center Pipe Outdoor Air guide (OA) Pipe Supply Air guide (SA) Pipe Return Air guide (RA) Pipe Exhaust Air guide (EA) VL-350CZPVU-R-E – Right Mounted Controller 20 192 222 20 222 192 209 112 55 84 623 15 242 658 242 242 350 377 149 106 10 432 200 200 200 40 246 460 40 736 30 φ145 Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Filter cover (OA) Filter cover (RA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Unit (mm) Wall mount hook center Pipe Outdoor Air guide (OA) Pipe Supply Air guide (SA) Pipe Return Air guide (RA) Pipe Exhaust Air guide (EA) VL-350CZPVU-R-E – Right Mounted Controller 20 10 432 200 200 200 40 246 460 40 736 pipe (SA) r supply cord r (RA) er (SA) Wall bracket (accessory) Unit (mm) Wall mount hook center e ply Air guide (SA) e urn Air guide (RA) oller 20 192 222 20 222 192 209 112 55 84 623 15 242 658 242 242 350 377 149 106 10 432 200 200 200 40 246 460 40 736 30 φ145 Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Filter cover (OA) Filter cover (RA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Unit (mm) Wall mount hook center Pipe Outdoor Air guide (OA) Pipe Supply Air guide (SA) Pipe Return Air guide (RA) Pipe Exhaust Air guide (EA) VL-350CZPVU-R-E – Right Mounted Controller Top View Front View Rear View Bottom View Side View

VL-500CZPVU-L-E Left sided Outdoor Air (OA) and Exhaust Air (EA) connections 254 250 254 250 134 20 289 φ 183 φ 157 49 (632) 14 242 120 725 32 748 235 51 235 424 453 265 219 10 556 20 40 40 29 223 223 223 236 482 185 447 Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Filter cover (OA) Filter cover (RA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Wall mount hook center Pipe Supply Air guide (SA) Pipe Return Air guide (RA) Pipe Outdoor Air guide (OA) Pipe Exhaust Air guide (EA) Unit (mm) VL-500CZPVU-L-E – Left Mounted Controller 254 250 254 250 134 20 289 φ 183 φ 157 49 (632) 14 242 120 725 32 748 235 51 235 332 144 381 378 173 10 556 20 4 4 223 Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Filter cover (RA) Filter cover (OA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Wall mou Outdoor Air Pipe guide (OA) Pipe Return Air guide (RA) Pipe guide (SA) Supply Air Pipe guide (EA) Exhaust Air VL-500CZPVU-R-E – Right Mounted Controller Unit (mm) Model VL-500CZPVU-L/R-E Electrical Power Supply 220–240V / 50Hz, 220V / 60Hz Ventilation Mode Heat Recovery Mode Heat Exchanger Type Sensible Heat Exchanger Fan Speed FS4 (100%) FS3 (70%) FS2 (50%) FS1 (30%) Running Current A 1.73 0.77 0.40 0.19 Input Power W 275 104 49 21 Air Flow m3/h 500 350 250 150 L/s 139 97 69 42 External Static Pressure Pa 200 98 50 18 Temperature Exchange Efficiency % 85 87 89 92 Sound Pressure Level at 3m dB 37 29 22 15> Energy Efficiency Class (ErP) A+ Weight kg 39 Dimensions (HxWxD) mm 632x725x556 Exchange efficiency (%) Static Pressure (Pa) Air volume Temperature exchange efficiency Performance Characteristic Curve VL-500CZPVU-L-E VL-500CZPVU-L/R-E Performance Characteristic Curve 254 250 254 250 134 20 289 φ 183 φ 157 49 (632) 14 242 120 725 32 748 235 51 235 332 144 381 378 173 10 556 20 223 Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Filter cover (RA) Filter cover (OA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Wall mou Outdoor Air Pipe guide (OA) Pipe Return Air guide (RA) Pipe guide (SA) Supply Air Pipe guide (EA) Exhaust Air VL-500CZPVU-R-E – Right Mounted Controller Unit (mm) 254 250 254 250 134 20 289 φ 183 φ 157 49 (632) 14 242 120 725 32 748 235 51 235 332 144 381 378 173 10 556 20 40 40 29 223 223 223 236 482 185 447 Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Filter cover (RA) Filter cover (OA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Wall mount hook center Outdoor Air Pipe guide (OA) Pipe Return Air guide (RA) Pipe guide (SA) Supply Air Pipe guide (EA) Exhaust Air VL-500CZPVU-R-E – Right Mounted Controller Unit (mm) 254 250 254 250 134 20 289 φ 183 φ 157 49 (632) 14 242 120 725 32 748 235 51 235 332 144 381 378 173 10 556 20 40 40 223 Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Filter cover (RA) Filter cover (OA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Wall mount Outdoor Air Pipe guide (OA) Pipe Return Air guide (RA) Pipe guide (SA) Supply Air Pipe guide (EA) Exhaust Air VL-500CZPVU-R-E – Right Mounted Controller Unit (mm) 10 556 20 40 40 29 223 223 223 236 482 185 447 n pipe (SA) Power supply cord over (RA) cover (SA) Wall bracket (accessory) Wall mount hook center Pipe Supply Air guide (SA) Pipe Return Air guide (RA) Unit (mm) roller 254 250 254 250 134 20 289 φ 183 φ 157 49 (632) 14 242 120 725 32 748 235 51 235 424 453 265 219 10 556 20 40 40 29 223 223 223 236 482 185 447 Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Filter cover (OA) Filter cover (RA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Wall mount hook center Pipe Supply Air guide (SA) Pipe Return Air guide (RA) Pipe Outdoor Air guide (OA) Pipe Exhaust Air guide (EA) Unit (mm) VL-500CZPVU-L-E – Left Mounted Controller Front View Front View Rear View Rear View Bottom View Bottom View Side View Side View 254 250 254 250 134 20 289 φ 183 φ 157 49 (632) 14 242 120 725 32 748 235 51 235 424 453 265 219 10 556 20 40 40 29 223 223 223 236 482 185 447 Drain pipe (EA) φ22 Drain pipe (SA) φ22 Power supply cord PCB Under Cover Filter cover (OA) Filter cover (RA) Filter cover (SA) Wall mount hook top Controller Heat exchanger Wall mount hook bottom Wall bracket (accessory) Wall mount hook center Pipe Supply Air guide (SA) Pipe Return Air guide (RA) Pipe Outdoor Air guide (OA) Pipe Exhaust Air guide (EA) Unit (mm) VL-500CZPVU-L-E – Left Mounted Controller Top View Top View VL-500CZPVU-R-E Right sided Outdoor Air (OA) and Exhaust Air (EA) connections PUBLISHED MAR 2024 www.mitsubishi-electric.co.nz | 0800 784 382
